The SilverStone 2U 750Rx Gold Power Supply features 80 PLUS Gold efficiency in a standard 2U Single form factor to assist with server compatibility. Supporting ATX 3.1 and PCIe Gen 5 standards with a 12V-2x6 connector, black flat cables, electrolytic capacitors, and a 60mm dual ball bearing fan, the power supply provides a reliable 750W of power for server and workstation systems.
Features
2U 750RX Gold
80 PLUS Gold 750W 2U Single Fixed Cable Power Supply
- Support standard 2U Single form factor
- Supports 12V-2x6 PCIe connector and compatible ATX 3.1 and PCIe Gen 5 standard
- Black flat cable design
- Main Japanese electrolytic capacitors
- Silent running 60mm dual ball bearing fan
- High efficiency with 80PLUS Gold certification
- 24/7 continuous power output with 50℃ operating temperature
Standard 2U Single Form Factor
Complies with the 2U Single standard to ensure high compatibility with server systems.
Compatible with Latest Power Standards
Compatible with ATX 3.1 and PCIe Gen5 standards.
80 PLUS Gold Certified
80 PLUS Gold certification delivers high efficiency, reducing energy loss and heat while providing stable and reliable power output.
Black Flat Cable Design
All-black flat cables make cable management easier, reduce clutter, and improve airflow inside the system.
Dual Ball Bearing Fan
Featuring a 60mm dual ball bearing fan for extended lifespan and superior durability, this design ensures reliable and efficient cooling performance, making it ideal for professional servers or workstations that operate under continuous high loads.
Specifications
| Model Number |
SST-2U750R-GF |
| Model (Safety Certification) |
SST-2U0750FCGD-A |
| Colour |
Black (lead-free paint) |
| Max. DC Output |
750W |
| Load Range |
Output: +3.3V +5V +12V +5VSB -12V
Max.(Amps): 25A 25A 62.5A 3.0A 0.3A
Min.(Amps): 0A 0A 0A 0A 0A
Range (%): ±5% ±5% ±5% ±5% ±10%
Line Reg.(%): ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p): 50mV 50mV 120mV 50mV 120mV |
| Combined +3.3V & +5V |
150W |
| Combined +12V |
750W |
| Input Voltage |
90 ~ 264 Vrms |
| Input Frequency Range |
47Hz ~ 63Hz |
| PFC |
Active PFC(PF>0.9 at full load) |
| Efficiency |
87% ~ 90% (at 20% ~ 100% loading) |
| MTBF |
100,000 hours |
| Operating Temperature |
0°C ~ 50°C |
| Protection |
Over power protection
Over current protection
Over voltage protection
Short circuit protection
Under voltage protection
Over Temperature protection |
| Connectors |
1 x 24/20-Pin motherboard connector
2 x 8 / 4-Pin EPS / ATX 12V connector
2 x 8 / 6-Pin PCIe connectors
1 x 12V-2x6 connector
6 x SATA connector
6 x 4-Pin Peripheral connector |
| Cooling System |
Single 60mm dual ball bearing fan |
| Noise Level |
18 dBA min. |
| Certification |
80 PLUS Gold |
| Form Factor |
2U Single |
| Dimension |
100mm (W) x 70mm (H) x 190mm (D)
Without bracket
3.46" (W) x 2.76" (H) x 7.48" (D) |
| Weight |
1.89kg |
Backed by a 3 year SilverStone warranty.
