The Simplecom CM401 Composite AV to HDMI Video Converter upscales analogue composite AV signals to HDMI output at 720p or 1080p (60Hz), supporting a range of PAL, NTSC and SECAM video standards. Featuring switch-selectable output resolution, integrated audio and video over HDMI, and USB power, the CM401 provides plug-and-play connectivity for compatible composite AV devices on modern HDMI displays.
Features
Simplecom CM401 Composite AV CVBS 3RCA to HDMI Video Converter 1080p Upscaling
Simplecom CM401 Composite AV to HDMI converter, is a universal converter for analogue composite input to HDMI 720p or 1080p (60Hz) output. If you want to use your VCR, camcorder, or game system on your HDTV or HDMI monitor, simply plug standard composite AV cables (yellow, red, and white) into the input port of the converter, and then connect an HDMI cable from the converter to your TV. It works great with either 720p or 1080p TVs, and the output mode is easily selectable with a switch on the device. This converter's advanced processing allowing you to get the clearest picture quality possible with optimal colour and detail reproduction. Both video and audio are integrated into the HDMI output, providing an all-digital signal to maximise the fidelity of the audio and video.
- Converts and up-scales analogue composite input to HDMI output
- Both video and audio are integrated into the HDMI output
- Advanced signal processing with great precision, colours, resolutions, and details
- No need to install drivers, portable, flexible, plug and play
- Supports NTSC and PAL Video Standards
- Supports HDMI 720p or 1080p (60Hz), switch selectable
- Powered by USB, plug into either a USB wall adaptor or a nearby USB port on TV
- Flexible Dual Power Source: USB Port, AC Power (5V/1A USB AC Adaptor Included)
Connection Chart
Place the Adaptor Next to TV (HDMI) is Recommended
- 50CM HDMI Cable Included
- Power Adaptor and USB Power Cable Included
- AV Cable NOT Included
Important Notes
- This adaptor is one way only, it converts from AV to HDMI only
- It's recommended to place the adaptor next to TV HDMI port
- USB power is required for this adaptor, the USB power cable can be plugged to the USB wall charger or USB port on TV
Specifications
| Model Number |
CM401 |
| Inputs |
AV Composite Signal (Yellow, White, Red) |
| Outputs |
HDMI |
| AV Standard Support |
PAL,NTSC3.58,NTSC4.43,SECAM,PAL/M,PAL/N |
| HDMI Output |
720p, 1080p (60Hz) |
| Dimensions |
55mm(W)x66mm(D)x 20mm(H) |
| Power Supply |
USB Power |
| Power Consumption (Max) |
5W |
| Weight |
40g |
| What's Included |
1x CM401 AV to HDMI converter
1x HDMI short cable
1x USB Power cable
1x USB Wall Adaptor |
Backed by a 1 year Simplecom warranty.
