MSI AMD EPYC 9005 Series NVIDIA MGX 4U Barebone GPU Server

Elevate your enterprise data centre capabilities with the MSI AMD EPYC 9005 Series NVIDIA MGX 4U Barebone GPU Server, a highly scalable infrastructure foundation engineered for demanding artificial intelligence and high-performance computing workloads. Built upon the highly adaptable NVIDIA MGX modular architecture, this robust 4U barebone system provides the flexibility to fully customise your computational hardware, arriving ready for you to install your preferred AMD EPYC 9005 series processors and memory. Designed for extreme processing density, the chassis is configured to accommodate up to eight high-end enterprise GPUs, making it an ideal platform for large language model (LLM) training, AI inference, and complex data simulations. To support rapid data access and expansive storage requirements, the server features eight front-accessible U.2 NVMe drive bays. Mission-critical reliability is ensured by a substantial (3+1) redundant configuration of 3,200W Titanium-grade CRPS power supplies, delivering exceptional energy efficiency and system stability under continuous heavy workloads. By offering a high-density, easily configurable framework that clearly outlines what you need to complete the build-noting that CPUs, RAM, and power cords are not included-this MSI barebone server delivers the advanced architecture required to confidently scale your modern IT operations.

For business enquiries, contact our B2B sales team here.

Features

---

S6053G480RAU8 Barebone GPU Server

• 4U (NVIDIA MGX™ architecture)
• Dual AMD EPYC™ 9005 series processors, TDP up to 500W
• (24) DDR5 RDIMM, 12 channels per CPU(1DPC), up to 6400MT/s
• (8) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays
• (2) 2280/22110 PCIe 3.0 x2 NVMe M.2 ports
• Max (13) PCIe 5.0 x16 expansion slots, supporting up to (8) NVIDIA H200 NVL or RTX
• PRO 6000 Blackwell Server Edition PCIe GPU cards
• (2) 10GBase-T Ethernet Ports with Intel® X710-AT2 (NCSI supported)
• (1) 1000Base-T Dedicated Server Management Port with:
• ASPEED AST2600 with IPMI 2.0 & DMTF Redfish Support
• Dual BIOS & BMC
• TPM2.0 on board
• Hardware Root of Trust available as an optional feature

Application

• Training, Fine Tuning
• LLM Inference
• NVIDIA Omniverse™
