Phanteks XT V5 Compact High Airflow ATX Case

PH-XT525V_DBK01 | Phanteks
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
$109
In stock
Order within 5h 4m 6s for next day dispatch!
Add to wishlist
Buy now, pay later!
Overview Specifications Warranty & Returns
Showcasing your high-end hardware through elegant front and side tempered glass panels, the Phanteks XT V5 Black is a remarkably compact mid tower chassis optimised to deliver exceptional thermal performance without dominating your desk space. This streamlined and striking visual case features an innovative internal layout that accommodates massive 430mm graphics cards and provides dedicated top clearance for a full 360mm liquid cooling radiator. To ensure your premium components remain perfectly stabilised and free from sag, Phanteks includes an adjustable GPU support bracket that secures directly to the steel chassis. Right out of the box, users can easily customise their system's airflow and RGB lighting using the four pre-installed 120mm ARGB fans (one S25-120 and one S25-360 cluster), which leverage a triple bottom-intake design to channel cool air directly onto the graphics card. While its stealthy black colour scheme blends beautifully into any professional or gaming environment, the front I/O panel stands out by offering an ultra-fast USB-C 3.2 Gen 2x2 port, ensuring 20Gbps high-bandwidth connectivity for modern external devices. By combining stunning panoramic visibility with robust capacity for up to seven 120mm fans and standard ATX power supplies, the XT V5 is perfect choice for your next enthusiast build.

Features

Phanteks XT V5 Compact High Airflow ATX Case add07

XT V5 Compact High Airflow ATX Gaming Chassis

The Phanteks XT V5 is a clean-looking compact ATX chassis that sits perfectly on your desk while housing powerful hardware. Its unique internal layout makes it possible to house a standard 360 radiator and ATX power supplies in such a compact form factor.

Thanks to its efficient layout, this case offers plenty of cooling options while maintaining a small footprint. Dedicated clearance in the top easily fits a 360 radiator, and even the largest GPUs are supported to build even the highest-end gaming systems. Fans are included with the S25-120 and S25-360, making this case fully equipped right out of the box.

With its innovative layout and strikingly clean design, the XT V5 is a compact mid-tower powerhouse ready for any cooling challenge.

The XT V5 comes with a glass front and side panel, offering a clear and stylish view of your system components. The triple-bottom fans offer direct cooling for your GPU. Choose the XT V5 if you want a great presentation case with great cooling.

Key Features

  • Compact, clean-looking ATX gaming chassis that fits perfectly on your desk
  • 10x/7x 120 mm fan locations for extreme cooling
  • Ample space for cable management makes installation smooth and simple
  • Pre-Installed 1x S25-120 & 1x S25-360 ARGB fans
  • Designed to handle the most powerful CPUs and GPUs with dedicated 360 radiator space in the top and ample GPU clearance
  • High Speed Type-C USB 3.2 Gen2x2 port and a USB 3.0 Type-A port
  • Safely secure the GPU with screws directly to the chassis with the GPU Support Bracket
  • Simply connect the ARGB lighting to the Mainboard or optional Phanteks Nexlinq Hub for lighting control

Clean Tempered Glass Aesthetic

  • Tempered glass front and side panels.
  • Minimal, modern exterior design.
  • Clear view of internal components.
  • Pre-installed S25 ARGB fans with vibrant lighting.
  • High-speed USB 3.2 Gen2x2 Type-C front I/O.

Full ATX Power in a Compact Footprint

  • Supports ATX, Micro-ATX and Mini-ITX motherboards.
  • Standard ATX power supply compatibility.
  • GPU clearance up to 430 mm.
  • GPU support bracket included.

Built for Smooth Installation

  • Accessible interior with smart cable pass-through points.
  • Optimised routing paths to simplify clean cable runs.
  • ATX power supply compatibility.

Storage

  • 2.5″ Storage Bracket - Supports 2x 2.5″ SSD drives.
  • 3.5″ Storage Bracket - Supports 1x 3.5″ HDD drives.

Fan Positions

  • 3x 120 mm top fans.
  • 1x 120 mm rear fan.
  • 3x 120 mm bottom fans.

Radiator Positions

  • 1x 360 top radiator up to 410 x 130 x 38 mm

Specifications

General

Model No. PH-XT525V_DBK01
Case Dimensions 452 x 235 x 430 mm | 17.79 x 9.25 x 16.93 in
From Factor Mid-Tower
Mainboard Support ATX | Micro-ATX | Mini-ITX
Materials Steel chassis | Tempered glass window | ABS plastic
Colour Black
Expansion Slots 7
Vertical GPU Support No
Internal 2.5” Positions 2
+ 1x 3.5" HDD
Internal 3.5” Positions 1
+ 2x 2.5" SSD
Front I/O 1x USB 3.0
1x USB-C 3.2 Gen2x2
1x Microphone | Headphone combo
Power button
Reset button

Fan Support

Total Fans 7x 120mm
Top 3x 120mm
Rear 1x 120mm (Pre-installed)
Bottom 3x 120mm (Pre-installed)

Radiator Support

Top supports up to 360

Clearances

GPU Length 430 mm | 16.93 in
GPU Width 175 mm | 6.89 in
GPU Support Bracket min. 298 mm, max. 370 mm
CPU Cooler Height 175 mm | 6.89 in
Power Supply 159 mm | 6.25 in
Top 360 Radiator 410 x 122 | 16.14 x 4.80 in

Additional Data

Net Weight 7.05 kg | 15.54 lbs
Warranty 5 Years Limited
What's Included 1x XT V5 chassis
1x S25-120 D-RGB fan Pre-installed
1x S25-360 D-RGB fan Pre-installed
1x Storage bracket Pre-installed
1x SSD bracket Pre-installed
Accessory Box 10x Zip ties
1x Stand-off removal tool
Screws 17x Mainboard | SSD screws
5x Power supply screws
4x HDD screws
2x thumbscrews
1x Mainboard stand-off
Backed by a 5 year Phanteks warranty.
