Phanteks XT M5 High Airflow Compact ATX Case

PH-XT525M_DBK01 | Phanteks
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
$109
In stock
Order within 5h 4m 15s for next day dispatch!
Add to wishlist
Buy now, pay later!
Overview Specifications Warranty & Returns
Engineered with an ultra-fine performance mesh front panel, the Phanteks XT M5 is a compact ATX mid tower chassis optimised to deliver maximum airflow and uncompromising cooling efficiency. This high performance case features an innovative internal layout that easily accommodates massive 430mm graphics cards alongside dedicated top clearance for a full 360mm liquid cooling radiator. To ensure your premium, heavy components remain perfectly stabilised and free from sag, Phanteks includes a dedicated, adjustable GPU support bracket that screws directly into the steel frame. Enthusiasts can easily customise their thermal configurations thanks to the chassis's massive capacity for up to ten 120mm fans, coming fully equipped right out of the box with four ARGB fans (one S25-120 and one S25-360 cluster) for immediate cooling superiority. While its stealthy black colour aesthetic blends seamlessly into any desktop setup, the modern front I/O panel stands out by providing an ultra-fast USB-C 3.2 Gen 2x2 port, ensuring 20Gbps high bandwidth connectivity for all your next-generation peripherals. By combining massive hardware compatibility with extreme ventilation capabilities, the XT M5 caters to flawlessly running builds that enthusiasts demand.

Features

Phanteks XT M5 High Airflow Compact ATX Case add1

XT M5 Compact Form Extreme Chassis

The Phanteks XT M5 is a clean-looking compact ATX chassis that sits perfectly on your desk while housing powerful hardware. Its unique internal layout makes it possible to house a standard 360 radiator and ATX power supplies in such a compact form factor.

Thanks to its efficient layout, this case offers plenty of cooling options while maintaining a small footprint. Dedicated clearance in the top easily fits a 360 radiator, and even the largest GPUs are supported to build even the highest-end gaming systems. Fans are included with the S25-120 and S25-360, making this case fully equipped right out of the box.

With its innovative layout and strikingly clean design, the XT M5 is a compact mid-tower powerhouse ready for any cooling challenge.

The XT M5 comes equipped with a mesh front panel and three pre-installed 120mm fans, offering a total of ten fan mounting positions to ensure excellent airflow throughout the system. Choose the XT M5 if you are looking for the best cooling capabilities.

Key Features

  • Compact, clean-looking ATX gaming chassis that fits perfectly on your desk
  • 10x/7x 120 mm fan locations for extreme cooling
  • Ample space for cable management makes installation smooth and simple
  • Pre-Installed 1x S25-120 & 1x S25-360 ARGB fans
  • Designed to handle the most powerful CPUs and GPUs with dedicated 360 radiator space in the top and ample GPU clearance
  • High Speed Type-C USB 3.2 Gen2x2 port and a USB 3.0 Type-A port
  • Safely secure the GPU with screws directly to the chassis with the GPU Support Bracket
  • Simply connect the ARGB lighting to the Mainboard or optional Phanteks Nexlinq Hub for lighting control

Engineered for Maximum Airflow

  • Ultra-fine performance mesh front panel for unrestricted intake.
  • Pre-installed S25 ARGB fans with vibrant lighting.
  • Support for up to 10 x 120 mm fans.
  • Dedicated 360 mm radiator space in the top.
  • Triple bottom intake positions for direct GPU cooling.
  • High-speed USB 3.2 Gen2x2 Type-C front I/O.

Full ATX Power in a Compact Footprint

  • Supports ATX, Micro-ATX and Mini-ITX motherboards.
  • ATX power supply compatibility.
  • GPU clearance up to 430 mm.
  • GPU support bracket included.

Built for Smooth Installation

  • Accessible interior with smart cable pass-through points.
  • Optimised routing paths to simplify clean cable runs.
  • ATX power supply compatibility.

Storage

  • 2.5″ Storage Bracket - Supports 2x 2.5″ SSD drives.
  • 3.5″ Storage Bracket - Supports 1x 3.5″ HDD drives.

Fan Positions

  • 3x 120 mm top fans.
  • 3x 120 mm front fans.
  • 1x 120 mm rear fan.
  • 3x 120 mm bottom fans.

Radiator Positions

  • 1x 360 top radiator up to 410 x 130 x 38 mm

Specifications

General

Model No. PH-XT525M_DBK01
Case Dimensions 452 x 235 x 430 mm | 17.79 x 9.25 x 16.93 in
From Factor Mid-Tower
Mainboard Support ATX | Micro-ATX | Mini-ITX
Materials Steel chassis | Tempered glass window | ABS plastic
Colour Black
Expansion Slots 7
Vertical GPU Support No
Internal 2.5” Positions 2
+ 1x 3.5" HDD
Internal 3.5” Positions 1
+ 2x 2.5" SSD
Front I/O 1x USB 3.0
1x USB-C 3.2 Gen2x2
1x Microphone | Headphone combo
Power button
Reset button

Fan Support

Total Fans 10x 120mm
Top 3x 120mm
Front 1x 360mm (Pre-installed)
Rear 1x 120mm (Pre-installed)
Bottom 3x 120mm

Radiator Support

Top supports up to 360

Clearances

GPU Length 430 mm | 16.93 in (without front fans)
GPU Width 175 mm | 6.89 in
GPU Support Bracket min. 298 mm, max. 370 mm
CPU Cooler Height 175 mm | 6.89 in
Power Supply 159 mm | 6.25 in
Top 360 Radiator 410 x 122 | 16.14 x 4.80 in

Additional Data

Net Weight 6.93 kg | 15.54 lbs
Warranty 5 Years Limited
What's Included 1x XT M5 chassis
1x S25-120 D-RGB fan Pre-installed
1x S25-360 D-RGB fan Pre-installed
1x Storage bracket Pre-installed
1x SSD bracket Pre-installed
Accessory Box 10x Zip ties
1x Stand-off removal tool
Screws 17x Mainboard | SSD screws
5x Power supply screws
4x HDD screws
2x thumbscrews
1x Mainboard stand-off
Backed by a 5 year Phanteks warranty.
