The Mercusys MS126CP 24 Port Gigabit Switch delivers high-density power and data connectivity with 24x 10/100 Mbps PoE+ ports, dual Gigabit uplinks, and up to 295W total PoE budget for surveillance, office, and business deployments. The Mercusys MS126CP 24 Port PoE+ Gigabit Switch is built for flexible network expansion and provides plug and play setup for fast and easy installation.
Features
24-Port 10/100 Mbps + 2-Port Gigabit Rackmount Switch with 24-Port PoE+
- 24 PoE+ Ports with 2 Gigabit Combo Uplink: 24x 10/100 Mbps PoE+ RJ45 ports , 2x Gigabit Combo RJ45 ports, and 2x Gigabit Combo SFP Slots
- High Power PoE+: Support PoE Power up to 30 W for each PoE port and 295 W for all PoE ports. (PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors) Working with IEEE 802.3af/at compliant PDs
- Long-Range up to 250 m: Increases PoE transmission distance to 250 m by Extend Mode (The speed of the ports which are under extend mode will be downgraded to 10 Mbps. Actual transmission distance may vary from the quality of the cables)
- Isolation Mode: One click to divide traffic for specific ports for stability and security
- Priority Mode: Guarantees the quality of sensitive applications like video monitor
- PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
- Plug and Play: No configuration or central management required
24 PoE+ Ports (295 W Budget) for Network Deployment
Ports 1-24 support PoE+, and each of them supports a maximum of 30 W. MS126CP provides 2 Gigabit combo ports (2 RJ45/2 SFP) for uplink devices. The total 295 W PoE power budget (PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors) for the 24x PoE+ ports can be applied in various scenarios, including surveillance, offices, and small businesses, since MS126CP is fully compatible with devices such as IP cameras, access points, IP phones, PCs, network video recorders, etc.
Long-Range Up to 250 m with Extend Mode
Extend Mode (The speed of the ports which are under extend mode will be downgraded to 10 Mbps. Actual transmission distance may vary from the quality of the cables) increases PoE transmission distance to 250 m. MS126CP has 24 long-range ports with PoE+. Turn on the Extend Mode and make it ideal for installing surveillance cameras over wide areas.
Traffic Separation
With only one click, isolation mode divides traffic for ports 1-24 to prevent snooping/tampering and isolate broadcast storms for greater protection.
Port Prioritisation
Prioritising the data of specific ports would ensure the high quality of delicate applications, such as voice and video.
PoE Auto Recovery
When a PoE-powered device stops sending data packets to the switch for an extended length of time, the switch will reboot it automatically.
Plug and Play
MS126CP offers auto-negotiation (10/100M) and automated MDI/MDIX. There is no additional configuration needed. It is simple to use and saves time and effort.
Surveillance
For IP Cameras
Business Wi-Fi
For Access Points
Office Networking
For Computers and Printers
Durable and Flexible
MS126CP’s durable metal case allows for efficient heat dissipation, excellent signal interference prevention, reliable equipment stability, and a long network life. And you can put the switch on desk or rack mount to meet your demand.
Backed by a 2 year Mercusys warranty.
