Hyte Y70 Touch Infinite Mid Tower Case Gundam Wing Edition

CS-HYTE-Y70TTI-GWING | Hyte
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
$599
In stock
Order within 4h 51m 58s for same day dispatch!
Buy now, pay later!
On sale! (normally $779) The Hyte Y70 Touch Infinite Mid Tower Case Gundam Wing Edition features a dual-chamber ATX mid tower design dressed in the iconic Wing Gundam Zero colourway with exclusive custom touchscreen firmware built into its integrated 14.9 inch IPS panel. It supports ITX, mATX, ATX and E-ATX motherboards, includes a PCIe 4.0 x16 riser cable for up to four vertical graphics slots, and offers extensive cooling with space for up to ten fans or multiple 360mm radiators for high-performance builds. The case includes top USB-C and USB-A ports, bottom and side dust filters, and ample airflow around GPUs up to 422mm in length and CPU coolers to 180mm in height. The case also includes features for Gundam Wing visuals and Nexus software support on the touchscreen for an immersive themed build.



Features


Gundam Wing Y70 Touch Infinite

Modern Aesthetic Case

Clad in its iconic Wing Gundam Zero colourway, this case celebrates 30 years of history with exclusive custom firmware built into the touchscreen. Inspired by its mecha origins, the Gundam Wing Y70 Touch Infinite is tailored to serious pilots and fans alike with a new way to house your system and favourite collectibles.

Mesmerising 14.9" Integrated IPS Touchscreen

At a 682 x 2560 (2.5K) resolution and 60Hz refresh rate, this capacitive IPS touchscreen delivers an insanely crisp and buttery smooth visual experience with 10-point multi-touch capability, unlocking a magnitude of possibilities and extensive screen customisation powered by HYTE Nexus software. Hyte's bigger, brighter, 3rd generation panel features a larger 14.9" display with a 43% higher brightness for a more immersive user experience. All in a single package integrated into the case chassis structure, pioneering meaningful digital interaction with the best display ever in a case.

Massive 4 Slot Vertical Graphics

Y70 grows GPU support to 4 slots with additional airflow space between the edge of the card and the glass. This means you can fit even the largest and most powerful of graphics cards into your build with ease. Additionally, the cold floor cooling down below can house up to a trio of 120mm or duo of 140mm fans up to 32mm thick to direct fresh airflow straight into the GPU.

Included Luxury PCIE 4.0 Riser Cable

Included with the case is a luxury PCIE 4.0 x 16 riser with a colour-matched canopy for uninterrupted visual flow that'll make for a painless GPU installation and build process. It also allows for a plethora of half-height PCIE cards to sit behind the throne of the vertical graphics.

Ginormous Cooling Capacity

A spacious interior makes room for up to a 360mm long & 125mm thick radiator on the side and adjustable top bracket that can house another 360mm radiator up to 68mm thick up above. Working together with the cold floor cooling at the bottom and spot for an additional fan at the rear of the case, Y70 has a total capacity of 10 fans in a fully populated chassis. With over 180mm of clearance to the side glass, air and water cooling enthusiasts alike will appreciate the flexibility afforded to them by the chassis to create the most robust cooling configurations possible.

Unified Modern Aesthetic

With 4 unique colourways, Y70 puts your build front and centre with a beautifully crafted 3-piece panoramic glass which serves as a window into the heart of your PC. The dual chamber interior layout keeps the front looking great while giving you plenty of space to manage cables in the back, especially with the help of a seamless L-shaped moulded rubber grommet, meticulously placed cable routing channels & tie-down points, and reusable Velcro straps. All easily accessible with tool-less top and side panels alongside floating storage sleds that eject from the rear of the case for intuitive drive maintenance.

Specifications


General Data

Model Number CS-HYTE-Y70TTI-GWING
Type Dual Chamber Mid-Tower ATX Case
Exterior Dimensions 470 x 320 x 470 mm
Volume (L) 70.7
Motherboard Sizes ITX, mATX, ATX, EATX
Expansion Slots 7 half + 4 full height
Riser Cable Included Yes, PCIE 4.0 x 16
I/O 1x USB-C 3.2 Gen 2, 2x USB-A 3.2 Gen 1, 1x 3.5mm Audio/Mic Combo Jack
Dust Filters Top, Side, Bottom
Top Fans 3x 120 mm / 2x 140 mm
Top Radiator 120-360, 140-280 @ 68 mm thick
Rear Fans 1x 120/140 mm
Rear Radiator 1x 120/140 mm
Side Fans 3x 120 mm / 2x 140 mm
Side Radiator 120-360, 140-280 @ 125 mm thick
Bottom Fans 3x 120 mm / 2x 140 mm @ 32 mm thick
Max Video Card Length 422 mm
Max Video Card Thickness 105 mm
Max CPU Cooler Height 180 mm
Max PSU Length 235 mm
Storage 2x 3.5" HDD or 4x 2.5" SSD
Warranty 4 Years

Touch Screen

Panel Technology IPS
Screen Size (Diagonal) 14.9 inches
Resolution 682 x 2560 (2.5K)
Pixels Per Inch 178
Dot Pitch 0.007 mm
Brightness 500 nits
Contrast Ratio 1000:1
Viewing Angle 80 degrees
Refresh Rate 60 Hz
Pixel Response Time 30 ms
Touch Input Yes, 10-Point Multi-Touch
Input Connections USB 2.0 Header, SATA Power, DisplayPort
Nexus Powered Yes, Nexus Touch
Backed by a 4 year Hyte warranty.
