The Cruxtec 10‑in‑1 USB‑C to Dual HDMI Mini Dock features dual HDMI outputs capable of up to 4K at 60Hz, a 100W USB‑C power delivery port for charging, a gigabit ethernet port plus a mix of USB‑A and USB‑C data ports for comprehensive connectivity. It supports USB‑C host connection and multi‑screen setups on Windows via MST/SST.
Features
Cruxtec 10-in-1 USB-C to Dual HDMI Mini Dock
Cruxtec compact mini dock connects various peripherals to devices, supporting up to 100W power delivery, Dual HDMI 4K output, Ethernet, and high-speed USB data transfer.
Built-In Gigabit RJ45 Network Interface
100W Power Delivery 3.0 Port
Up to 85W power delivery to laptop for faster charging.
Dual HDMI Output with 3.5mm Audio Jack
Supports Dual HDMI Output Up to 4K@60Hz
2 x USB3.0 5Gbps Type-A Ports - 1 x USB3.0 5Gbps Type-C Port - 2 x USB2.0 480Mbps Type-A Ports
Multi-Screen Extension
Support Windows Systems
Supports MST/SST on Windows, Supports resolution up to 4K@60Hz in multi-screen output: The device needs to support HBR3 bandwidth or above.
01. Extended Mode
Laptop screen + two monitors Triple Screen Different Display.
02. Mirror Mode
The laptop screen and two external monitors mirror the same content.
03. Extended Mode
The laptop screen and two external monitors show different content.
Support Mac OS Systems
- On Mac OS with M1 CPU only supports 1 external monitor display in USB-C Display Alt mode; Supports resolution up to 4K@60Hz.
- On Mac OS with M2/M3 CPU supports multi-screen mirroring or extending; Supports resolution up to 4K@60Hz in multi-screen output.
01. Mirror Mode
The laptop screen and two external monitors mirror the same content.
02. Extended Mode
The laptop screen and two external monitors show different content.
Specifications
| Model Number |
CRUXTEC-CDK10-SG |
| Interface |
2 x HDMI Output Ports Support up to 4K@60Hz.
1 x 100W Power Delivery 3.0 Port.
1 x USB-C Port for Host Connection.
1 x Gigabit Ethernet Port.
2 x USB3.0 5Gbps Type-A Ports.
1 x USB3.0 5Gbps Type-C Port.
2 x USB2.0 480Mbps Type-A Ports.
1 x 3.5mm Audio Jack.
Supports MST/SST on Windows; Supports resolution up to 4K@60Hz in multi-screen output;
The device needs to support HBR3 bandwidth or above.
On Mac OS with M1 CPU only supports 1 external monitor display in USB-C Display Alt mode; Supports resolution up to 4K@60Hz.
On Mac OS with M2/M3 CPU supports multi-screen mirroring or extending; Supports resolution up to 4K@60Hz in multi-screen output.
Supports only mirroring on Android. |
| Chipset Solution |
Capstone, Realtek, Genesys |
| Cable Length |
15cm |
| Warranty |
1 Year |
Backed by a 1 year Cruxtec warranty.
