The TP-Link POE260R Omada 2.5G PoE+ Splitter features 2.5 Gigabit Ethernet speeds and supports IEEE 802.3af/at standards for efficient power and data delivery. It offers selectable 12V, 9V, or 5V DC output to power non-PoE devices without the need for a separate power adapter.
Features
Omada 2.5G PoE+ Splitter
- IEEE 802.3af/at compliant
- Selectable power output
- 2.5 Gigabit speed support
- Plug-and-Play, no configuration required
What This Product Does
The POE260R is a 2.5 Gigabit PoE+ splitter that delivers high-speed data and converts standard PoE+ input into a flexible 12V/9V/5V DC output, powering various devices over existing network cables without requiring a separate power adaptor.
Specifications
General Data
| Model Number |
POE260R |
| Warranty |
3 Years |
| Certification |
FCC, CE, RoHS |
| What's Included |
POE260R
Power Cord
Installation Guide |
| Environment |
Operating Temperature:-5~45 (23~113)
Storage Temperature: -40~70 (-40~158)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
Hardware Features
| Interface |
10M/100M/1000M/2.5Gbps Auto-Negotiation RJ45 POWER+DATA IN Port
10M/100M/1000M/2.5Gbps Auto-Negotiation RJ45 LAN OUT Port
12V / 9V / 5V DC OUT Power Output Port |
| Network Media |
10BASE-T:2-pair UTP/STP of Cat. 3,4,5 (maximum 100 m)
100BASE-TX:2-pair UTP/STP of Cat. 5 or above (maximum 100 m)
1000BASE-T:4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
2.5GBASE-T:4-pair UTP/STP of Cat. 5e or above (maximum 100 m) |
| Power Supply |
12VDC/ 2A,9VDC/ 2A or 5VDC/ 2A |
| Basic Function |
Compatible With IEEE 802.3af/at Compliant PSEs
Delivers Power Up To 100 Metres
Optional 12VDC, 9VDC or 5VDC Power Output |
| LED |
PWR |
| Dimensions ( W x D x H ) |
3.2 x 2.1 x 0.9 in. (80.8 x 54 x 24 mm) |
Software Features
| Basic Function |
Compatible With IEEE 802.3af/at Compliant PSEs
Delivers Power Up To 100 Metres
Optional 12VDC, 9VDC or 5VDC Power Supply |
Backed by a 3 year TP-Link warranty.
