The FSP HV PRO Bronze ATX 650W Power Supply features 80 PLUS Bronze certification, delivering over 85% energy efficiency under typical loads. It complies with ATX12 v2.52 and EPS12 v2.92 standards, ensuring stable and efficient operation.
Features
HV PRO 650W
- Complies with ATX12 v2.52 & EPS12 v2.92
- Efficiency 85% at typical Load
- Active PFC ≧ 0.9
- Hold up time > 17ms at 80% Load
- +12V Single-Rail Design
- +5V &3.3V DC to DC Module Design
- 120mm Silent & long life Fan
- Complete Protections: OCP/OVP/OPP/SCP
True Power, You Can Count On
With 0.9 Active Power Factor Correction, the V PRO series comes across with guarantee wattage of continuous power, delivers full power to your PC system.
Dual CPU Power Connectors
For gaming enthusiast, the HV PRO series features with dual CPU power connectors to support high-end motherboard and provide CPU stable power.
Optimal Cooling
An advanced thermal control fan makes optimal cooling and reduces noise under maximum operation.
Stable DC to DC Output Quality
For maximum efficiency and stable voltage, HV PRO series with DC to DC circuit design offers benefits such as better compatibility and reliability, and high system compatibility especially in cross regulation mode.
Global Safety Standard
HV PRO series follows global safety standard, its grounded design can enhance current stability and ensure safety under maximum operation.
80 Plus® Certification
HV Pro series meet 80 PLUS 230V EU Standard and rated for greater efficiency to 85%, so you'll enjoy lower energy bills.
Specifications
General Data
| Model Number |
FSP-PPA6505410 |
| Model |
FSP650-51AAC |
| Rated Output Power |
650W |
| Form Factor |
ATX |
| 80 PLUS Certification |
230V EU Standard |
| Input Voltage |
200-240Vac |
| Input Current |
5A |
| Input Frequency |
50-60Hz |
| PFC |
Active PFC |
| Efficiency |
≥85% at typical load |
| Fan Type |
Sleeve Fan, 120mm |
| Dimensions(L x W x H) |
150 x 140 x 86mm |
| Protection |
OCP, OVP, OPP, SCP |
| Warranty |
3 Years |
Load Range
| DC Output |
+3.3V |
+5V |
+12V |
-12V |
+5Vsb |
| Max Output Current |
20A |
20A |
54.1A |
0.3A |
2.5A |
| Max Combined Power |
100W |
100W |
649.2W |
3.6W |
12.5W |
| Total Power |
650W |
650W |
650W |
650W |
650W |
Cables
| - |
ATX 24 |
4+4 PIN |
PCI-E 6+2 |
SATA |
Molex (Peripheral) |
Floppy |
| Connectors |
1 |
2 |
2 |
4 |
2 |
1 |
Backed by a 3 year FSP warranty.
