The Phanteks XT M3 DRGB Tempered Glass Micro ATX Case White features a compact micro-ATX design with a sleek white steel chassis and tempered glass side panel, ensuring a clean and modern aesthetic. It supports up to nine 120mm fans, including triple bottom-mounted fan locations for direct GPU cooling, and offers dedicated top-mounted radiator space for efficient airflow and cooling performance.
Features
XT M3 Compact Micro ATX Gaming Chassis
The XT M3 is a powerful yet compact microATX chassis ready for any gaming PC configuration. Plenty of fan positions, including triple 120 fan positions in the bottom and dedicated radiator space in the top, provide plenty of cooling options within its sleek and clean appearance.
With its innovative layout and strikingly clean design, the XT M3 is a microATX powerhouse ready for any cooling challenge.
Compact Gaming Chassis
- Supports a total of nine 120 fans for powerful cooling within this compact chassis.
- Dedicated 360 radiator space in the top of the chassis.
- Triple fan locations in the bottom for direct GPU cooling.
Organised by Design
- Spacious cable routing area for clean and efficient management.
- Fully compatible with Rear-Connect mainboards for streamlined builds.
Fan Positions
- 3x 120 mm top fans.
- 2x 120 mm front fans.
- 1x 120 mm rear fan.
- 3x 120 mm bottom fans.
Radiator Positions
- 1x 360 top radiator up to 410 x 122 x 60 mm
Storage
- SSD Storage Bracket - Supports 2x 2.5″ SSD drives.
- HDD Storage Bracket - Supports 1x 3.5” HDD drive.
Specifications
General Data
| Model Number |
PH-XT325M_DWT01 |
| Case Dimensions |
460 x 235 x 370 mm | 18.1 x 9.3 x 14.6 in |
| From Factor |
Compact microATX tower |
| Mainboard Support |
Micro-ATX | Mini-ITX |
| Materials |
Steel chassis | Tempered glass window | ABS plastic |
| Colour |
White |
| Expansion Slots |
4 |
| Vertical GPU Support |
No |
| Internal 2.5″ Positions |
2 + 1x 3.5" HDD |
| Internal 3.5″ Positions |
1 + 2x 2.5" SSD |
| Front I/O |
1x USB 3.0
1x USB-C 3.2 Gen2x2
1x Microphone | Headphone combo
Power button |
Fans
| Total Fans |
9 x 120 |
| Top |
3 x 120 |
| Front |
2 x 120 |
| Rear |
1 x 120 |
| Bottom |
3 x 120 |
Radiator
Clearance
| CPU Cooler Height |
175 mm | 6.88 in |
| GPU Length |
430 mm | 15.94 in
Without front fans installed |
| GPU Width |
175 mm | 6.88 in |
| Power Supply |
150 mm | 5.90 in |
| Top 360 Radiator(L x W x H) |
410 x 122 x 60 mm | 16.14 x 4.80 x 2.36 in |
Extra
| Net Weight |
5.57 kg | 12.28 lbs |
| Warranty |
5 Years Limited |
| Scope of Delivery |
1x XT M3 chassis
1x SSD bracket Pre-installed
1x HDD bracket Pre-installed |
| What's Included |
9x Zip ties
1x Stand-off removal tool
1x GPU support |
| Screws |
17x Mainboard | SSD screws
5x Power supply screws
4x HDD screws
1x Mainboard stand-off |
Backed by a 5 year Phanteks warranty.
