The Ubiquiti UISP Cable Pro Industrial-grade Outdoor Cable 305m is a Category 5e Ethernet cable designed for outdoor installations. It features a weatherproof polyethylene jacket, internal foil shielding and an integrated ESD drain wire, providing protection against electrostatic discharge and electromagnetic interference. With 24 AWG solid copper conductors, the cable supports Gigabit Ethernet speeds and is suitable for Power over Ethernet applications.
Features
Industrial-Grade Outdoor Cable
Designed for rugged outdoor environments, providing reliable performance and long-term durability.
High-Speed Data Transmission
Supports stable, high-speed networking for UISP and other network devices over long distances.
UV and Weather Resistant
Constructed with weatherproof and UV-resistant materials to withstand harsh conditions and prolonged sun exposure.
Long 305m Length
Provides ample cable length for large-scale deployments and extended network setups.
Flexible Installation
Durable yet flexible design allows easy routing and installation in outdoor and industrial environments.
Reliable Connectivity
Ensures stable, high-quality signal transmission even in challenging outdoor conditions.
Specifications
| Model Number |
UISP-CABLE-PRO |
| Cable Length |
305 m (1,000 ft) |
| Cable Colour |
Black |
| Cable Type |
CAT5e, shielded |
| UV Resistance |
ASTM G 151/154 |
| Ethernet Support |
Up to 1 Gbps |
| Conductor Wire Gauge |
24 AWG |
| Conductor |
Solid bare copper |
| Conductor Diameter |
0.500 ± 0.005 mm |
| Insulation Type |
Solid polyethylene |
| Insulation Thickness |
Avg. 0.26 mm
Min. 0.25 mm |
| Insulation Diameter |
1.04 ± 0.03 mm |
| Separation (Polyester Wrapping) |
Thick: 0.025 mm
Extent: 20 mm |
| Anti-Crosstalk Divider |
None |
| Cable Shield (Aluminium Foil) |
Thick: 0.060 mm
Extent: 18 mm |
| ESD Drain Wire |
0.4 CCS |
| Rip Cord |
Yes |
| Jacket Material |
Polyethylene |
| Jacket Thickness |
Avg. 0.50 mm
Min. 0.46 mm |
| Jacket Outer Diameter |
6.0 ± 0.30 mm |
| Jacket Colour |
Black |
| Storage Temperature |
-30 to 75° C (-22 to 167° F) |
| Installation Temperature |
-20 to 60° C (-4 to 140° F) |
| Ambient Operating Temperature |
-40 to 80° C (-40 to 176° F) |
| Standards |
ANSI/TIA-568-C.2 (2009)
ISO/IEC 11801 (Edition 2.2) |
| NDAA Compliant |
Yes |
| Warranty |
1 Year |
Backed by a 1 year Ubiquiti warranty.
