The Cooler Master Elite 690 Wood Dual Chamber Case combines natural aesthetics with modern performance, featuring a real wood-textured front panel and dual panel 270 degree tempered glass for a clean, panoramic view of your build. Its vertical airflow design supports up to ten fans, with three pre-installed ARGB fans and space for top 360mm and side 240mm radiators to ensure excellent cooling. A dedicated dual-chamber layout keeps cables neatly managed and airflow unobstructed, making the Elite 690 Wood an ideal choice for builders who want elegant design paired with high-end thermal performance.
Features
Elite 690 Wood
Natural Aesthetics. Immersive View. Advanced Cooling.
The Elite 690 features dual tempered glass panels to showcase your build, while a wood-textured front accent and mesh intake blend warmth with airflow efficiency. With top and bottom ventilation for vertical cooling, it supports versatile fan and radiator setups—perfect for performance-driven or style-focused builds.
270° Panoramic Tempered Glass
Bevelled glass panels create an immersive, seamless showcase of your build.
Optimised Tower with PSU Chamber
Vertical layout separates thermal zones for better airflow and cleaner cable routing.
Vertical Cooling Architecture
Up to 10 fans in a bottom-to-top layout maximise airflow and cooling.
Natural Wood Front Panel
Crafted from real wood, the front panel adds a warm, organic touch to any space.
High-Performance Radiator Support
Top 360mm and side 240mm radiator support for powerful cooling setups.
Pre-Installed ARGB Fans with Sync
Includes 3 daisy-chainable ARGB fans with full motherboard lighting sync support.
Top & Bottom Mesh Ventilation
Mesh panels ensure enhanced airflow and system-wide thermal performance.
Next-Gen GPU Ready
Supports up to 425mm GPUs—ready for RTX 50 Series and beyond.
High-Speed I/O Panel
USB 3.2 Gen 2x2 Type-C and dual USB 3.0 ports for blazing-fast connectivity.
- Type C
- Type A
- 3.5mm Audio + Mic
Specifications
| Model Number |
E690-WHNN-S00 |
| Colour |
White |
| Materials - Front Panel |
Tempered Glass + Wood |
| Material - Side Panel (Left) |
Tempered Glass |
| Material - Side Panel (Right) |
Steel |
| Dimensions (L x W x H) |
434 x 218 x 454 mm (Incl. Protrusions), 430 x 218 x 435 mm (Excl. Protrusions) |
| Volume |
42.93 L (Litres Incl. Protrusions) |
| Motherboard Support |
ITX / Micro-ATX / ATX |
| Expansion Slots |
7 |
| 3.5" Drive Bays |
1 (Max. 2) |
| 2.5" Drive Bays |
1 (Max. 2) |
| I/O Panel - USB Ports |
1 x USB Type C 20Gbps, 2 x USB 3.0 |
| I/O Panel - Audio In / Out |
1x 3.5mm Combo |
| Pre-Installed Fans - Rear |
1x 120mm ARGB PWM |
| Pre-Installed Fans - Side Mount |
2x 120mm ARGB PWM reverse fan |
| Fan Support - Top |
2x 140mm / 3x 120mm |
| Fan Support - Rear |
1x 120mm |
| Fan Support - Side Mount |
2x 120mm |
| Fan Support - Bottom |
3x 120mm |
| Radiator Support - Top |
120 / 240 / 360 (Max height 45mm) |
| Radiator Support - Bottom |
120 / 240 / 360mm |
| Radiator Support - Side Mount |
120 / 240mm |
| Clearance - CPU Cooler |
170mm |
| Clearance - PSU |
250mm |
| Clearance - Graphics Card |
425mm |
| Power Supply Support |
ATX |
| Warranty |
2 years |
| Size |
Mid Tower |
| Series |
Elite Series |
Backed by a 2 year Cooler Master warranty.
