(Epic Price!) The Cooler Master NCORE 100 Air is a compact Mini-ITX case designed for high-performance builds in small spaces. It supports triple-slot GPUs up to 336mm in length, making it compatible with large graphics cards. The case features an anodized aluminium shell and a tool-less design for easy assembly. Its efficient thermal layout draws air through the side panels to keep components cool. Front I/O includes USB 3.2 Gen 1 Type-A and USB 3.2 Gen 2x2 Type-C ports.
Features
Cooler Master Ncore 100 Air
Max Performance, Minimalist Design
- Latest Gen GPU Compatibility
- Ultra-Small Footprint
- Extendable Frame Design
- Open and Toolless Frame Design
- Thermal Efficient Layout
The Compact Case for Powerful PC
Ncore 100 Air is designed with space-saving and performance in mind. With its small footprint and minimalistic design, Ncore 100 Air is versatile for gamers and content creators. The Ncore 100 Air offers ample space for the latest-generation GPUs, while its thermal layout ensures efficient airflow for optimal cooling.
Latest Gen GPU Compatibility
Supports triple-slot graphics cards up to 336 mm in length. The PCIe slot is adjustable to accommodate cards up to 356 mm, ensuring compatibility with the latest-generation GPUs.
Efficient Thermal Layout
The Ncore 100 Air layout has been meticulously designed to offer the most efficient thermal layout. This layout pulls in air from the standing sides of the case, which are its largest surface.
Premium Aluminium Panel
An anodised aluminium shell makes the Ncore 100 Air stand out as a desktop work of art.
Ultra-Small Footprint
The Ncore 100 Air is super compact, with a footprint about the size of a small booklet.
Extendable Frame Design
The Ncore 100 Air has a compact volume of just 14.7L; however, its frame is designed to expand up to 16.4L when needed.
Open and Toolless Frame Design
Based on Cooler Master’s ‘Make It Yours’ and staying true to our audience, the open frame design make it easy to build or upgrade the PC. Even the cover features tool-less removal for maximum accessibility.
Specifications
| Model Number |
NR100-KNNN-S00 |
| Exterior Colour |
Black |
| Materials - Exterior |
Steel, Plastic, Aluminium |
| Materials - Side Panel |
Aluminium |
| Motherboard Support |
ITX |
| Graphic Card Support |
Triple Slot 336 mm length and 140 mm height (PCIe slot can be adjusted for 356 mm GPU length) |
| Expansion Slots |
2x PCIe Slot Mounting |
| Drive Bays - 2.5" SSD |
1 |
| I/O Panel - USB Ports |
2x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2x2 Type-C |
| I/O Panel |
1x Audio Combo (Audio In / Out 3.5 mm) |
| Clearances - CPU Cooler |
50 / 70 mm |
| Clearances - Power Supply |
100 mm |
| Clearances - RAM |
50 / 70 mm |
| Clearances - Graphics Card |
50 mm CPU Cooler: 337 x 62 x 180 mm / 357 x 79 x 180 mm (expansion) (max. space incl. GPU power connector), 70 mm CPU Cooler: 337 x 42 x 180 mm / 357 x 59 x 180 mm (expansion) (max. space incl. GPU power connector) |
| Pre-Installed Fan(s) - Top |
120 mm CS120 PWM Fan (max. 1200 RPM) |
| Pre-Installed Fan(s) - Rear |
120 mm CS120 PWM Fan (max. 1200 RPM) |
| Dust Filters |
Side panels |
| Cable Routing - Behind MB Tray |
11 mm |
| Power Supply Support |
SFX |
| Included Accessories |
1x 240 PCIe 4.0 x 16 Riser Cable, 1x ATX 3.0 power cable for vertical mount |
| Volume |
14.7 L / 16.4 L (incl. protrusions) |
| Dimensions (L x W x H) |
155 x 212 x 449 mm / 172 x 212 x 449 mm (Incl. Protrusions), 155 x 212 x 425 mm / 172 x 212 x 425 mm (Excl. Protrusions) |
| Warranty |
2 years |
| Size |
Mini ITX |
Backed by a 2 year Cooler Master warranty.
