The Gigabyte B760M Gaming X AX Gen5 DDR5 Motherboard supports 14th, 13th and 12th Gen Intel Core processors, and LGA 1700 sockets, features up to 4 x DDR5 memory slots, PCI-E 5.0 and 3.0 compatible expansion slots, 2 x M.2 slots, 4 x SATA ports (6Gb/s), 8 x rear USB ports, Realtek 2.5Gb LAN, AMD Wi-Fi 6E AX210, Bluetooth 5.3, and a micro ATX motherboard form factor.
Warning: This product contains a button battery
- If swallowed, a lithium battery can cause severe or fatal injuries with 2 hours.
- Keep batteries out of reach of children.
- If you think batteries may have been swallowed or placed inside any of the body, seek immediate medical attention.
|
Features
B760M Gaming X WiFi6E Gen5
- PCIe Gen5 Performance : Perfect Sync to Win
- Supports Intel® Core™ 14th/ 13th/12 processors
- Efficient Thermal : VRM Thermal Armour Advanced & M.2 Thermal Guard
- WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
- WIFI Compass : Auto detects the best antenna position for strongest Wi-Fi signal
- EZ-Latch : PCIe 5.0x16 Slot with Quick Release Design
- PCIe UD Slot : SMD PCIe 5.0 Armour for enhanced graphics card support
- Unparalleled Performance : Hybrid 8+1+1 Phases VRM Solution
- Dual Channel DDR5 : 4*DIMMs with XMP Memory Module Support
- Fast Networks : 2.5GbE LAN & Wi-Fi 6E 802.11ax
- Extended Connectivity : Front USB-C® 10Gb/s, DP, HDMI
- Next Generation Storage : 2*PCIe 4.0 x4 M.2 Connectors
- Smart Fan 6 : Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
- Q-Flash Plus : Update BIOS Without Installing the CPU, Memory and Graphics Card
Performance
- UD Power Connector
24 pin ATX Power Connector
8 pin CPU with UD Solid Pin
- 8+1+1 Hybrid Phases Power
60A DrMOS
PCIe 5.0 Ready PCB
6-Layer PCB
- Full-length PCIe slots
1 x PCIe 5.0 x16 with PCIe UD Slot
1 x PCIe 3.0 x16 slot (runx4)
- Support 14th and 13th Gen. Intel® Core™ Processors
- 4 x DIMMs, Dual Channel DDR5
- 2 x M.2 Slots
2*PCIe 4.0 x4 M.2
Thermal
- VRM Thermal Armour Advanced
- M.2 Thermal Guard
Connectivity
- 5 x USB 2.0
- Wi-Fi 6E 802.11ax
- WIFI EZ-Plug
- 1 x HDMI
- 1 x Display Port
- 3 x USB 3.2 Gen 1
- 2.5 GbE LAN
- Hi-Fi Audio
8-CH HD Audio
High-End Audio Capacitor
- Front USB-C 10Gb/s
- 4 x SATA 6Gb/s
- RGB FUSION
3 x Addressable LED Headers
1 x RGB LED Header
DIY Friendly
- WIFI EZ-Plug
- Q-Flash Plus
- PCIe EZ-Latch
PCIe Gen5
Express to PCIE5 Performance
The new GIGABYTE B760 motherboards provides the most efficient solution to enjoy boosted performance of PCIe Gen5 on the existing platform. PCIe 5.0 doubles the data transfer rate of PCIe 4.0 from 16 GT/s to 32 GT/s per lane. This substantial increase in bandwidth particularly benefits high-performance graphics cards, storage devices, and AI accelerators that demand faster data movement.
- PCIe Gen5 - 32GT/s Speed per lane (2X Speed Boost)
- PCIe Gen4 - 16GT/s Speed per lane
Cooling
Fully Covered Thermal Design
High coverage MOSFET and integrated moulding Heatsinks to improve thermal efficiency with better airflow and heat exchange.
Fully Covered MOSFET Heatsink
- 4X Massive cooling surface - Advanced heat dissipation
- 5 W/mK thermal pad
4X Large Surface
Increased surface area up to 4X larger compared to traditional heatsinks. It improves heat dissipation from the MOSFETs.
Real One-Piece Build
TMOS is a TRUE single piece heatsink. Its one-piece design and larger surface drastically improve the cooling performance against competitors' multi-piece design.
Multi-Cut Design
TMOS features several channels and inlets on the heatsink. This design allows for the air flow to go through which leads to a great improvement of the heat transfer performance.
M.2 Thermal Guard
The M.2 Thermal Guard prevents throttling and bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.
Smart Fan 6
Cool. Quiet. Customised.
Superior cooling performance and whisper-quiet operation for your gaming rig.
High Current Support
- Supports both PWM and DC fans, plus water cooling pumps
- Up to 24W (12V x 2A) capacity per fan header
- Built-in over-current protection
Precision Control
- Multiple temperature and fan speed points
- Customisable fan curves for optimal performance
Dual Curve Mode
- Choose between slope and stair modes
- Tailor cooling to your specific needs and preferences
Fan Stop Technology
- Fans can be completely turned off at low temperatures
- Ensures silent operation during light loads
Smart Fan 6 BIOS UI
Enhance Fan Curve UI
- 7 adjustable control points
- Expanded speed graph for precise adjustments
Slope/Stair Dual Graph Mode
- Slope mode: Smooth fan speed curve
- Stair mode: Steady speeds within temperature ranges
- Easy switching between modes
Manual Input
- Fine-tune fan speeds for optimal performance
- Precise control for enthusiasts
EZ Tuning
- Quick setup with 4 temperature and fan speed points
- Automatic optimisation of fan curve
Fan Curve Profile
- Save personalised settings to BIOS ROM
- Maintain custom settings through BIOS updates
Easy & Friendly
Hassle-Free Assembly
Our cutting-edge motherboard is designed for the ultimate DIY experience.
WiFi EZ-Plug
The WIFI EZ-Plug design integrates Wi-Fi antenna plugs into one adaptor, EZ to install.
WiFi Compass
Features auto detection to help users find the best antenna position for stronger Wi-Fi signal.
- Easy-to-use interface guides users to measure without expertise: 4D Mode (4 Detection Mode) - Built for everyday use
- CD Mode (Continuous Detection Mode) - Designed for technical enthusiasts.
EZ-Latch Designs
User-friendly designs simplifying the assembly process.
PCIe EZ-Latch
Unlock the latch of the PCIe slot easily when remove the graphics card in the PCIe slot.
Fast-Access Controls
Handy, Revert, Refresh
Q-Flash Plus
Effortlessly upgrade your BIOS without the need to install CPU, RAM, or GPU.
Step 1
Connect the 24-pin and 8-pin power cables directly to the motherboard.
Step 2
Download the motherboard's BIOS file, rename it to 'gigabyte.bin', and store it on a FAT32-formatted USB drive. Insert the drive into the Q-FLASH PLUS USB port.
Step 3
Press the Q-FLASH PLUS button to trigger automatic BIOS updating.
Ultra Durable™
Born from Ultra Durable™
Technology embodies our commitment to excellence, providing gamers with a platform that's not only powerful but also built for longevity and reliability. GIGABYTE motherboards are engineered to endure and excel.
PCIe UD Slot
GIGABYTE's one-piece stainless-steel shielding design reinforces the PCIe Slots, providing the extra strength required to support heavy graphics cards.
- 1.7X stronger shearing test
- 3.2X stronger retention force test
- Reduced Signal Degradation with SMD Technology
UD Power Connector
Our innovative UD Power Connector design enhances power conductivity and thermal dissipation.
Solid Pins
Delivers superior conductivity and signal transmission and reduces metal wear from repeated connections.
Memory
Unlock DDR5 Performance
GIGABYTE is offering a tested and proven platform with extreme memory performance boost.
- DDR5 Overclocking Up to 7800 MT/s
* Memory overclocking and XMP profile support may vary depending on hardware configuration.
* Please see the complete validated memory support list. Product features may vary by model.
BIOS Features
Unlock DDR5 Voltage
GIGABYTE Exclusive DDR5 Circuit Design Increases DDR5 memory overclocking performance and capability by transforming Native DDR5 memory module to Overclocked DDR5 memory.
Secure Mode
Motherboard provides fixed 5V to Native DDR5 memory and built-in PMIC outputs locked 1.1v to memory IC.
- Unlocks Native DDR5 PMIC secure mode into programmable mode and controls Native DDR5 voltage with wide range.
- Supports all PMIC vendors for maximum compatibility.
- Memory overclocking capability will vary based on users' hardware configuration.
Achieve Higher DDR5 Memory Frequencies with Ease
DDR5 XMP Booster function provides optimised pre-defined profiles, based on memory IC and PMIC vendor analysis, for effortless performance enhancement and elimination of manual configuration for overclocked DDR5 memory kits.
Accelerate Instantly
Boost memory performance instantly.
Automate Input
No need to manually configure multiple memory parameters like clock, voltage, and timings.
Streamline Overclocking
Easily overclock Native and XMP 3.0 DDR5 memory to higher frequencies.
Integrate Database
Built-in database of pre-tuned profiles for different memory IC vendors.
* DDR5 MEMORY UPGRADE involves DDR5 memory overclocking, overclocking capability depends on users' hardware configuration.
Maximise DDR5 Performance with Your Memory Settings
XMP 3.0 User Profile empowers you to optimise your memory settings and achieve the best performance for your system.
SPD Re-Defined or Retrieve from Database
Users can define two empty SPD profiles and transfer them to another computer.
Performance Simulation
Simulate memory performance quickly by inputting clock and timing parameters.
Save/Load Profile
Save and load memory profiles for online sharing.
Boost Non-Overclockable DDR5 Memory Frequency
Increase the frequency of non-overclockable DDR5 memory.
One-Click Clear Profile
Reset memory settings conveniently.
Unmatched Hardware Excellence
Shielded Memory Routing
All memory routing is under the PCB inner layer shielded by a large ground layer to protect from external interference.
Impedance Optimised Topology
By optimising memory trace width, length and style from HPC simulation to actual implementation, overall impedance is lowered between CPU memory controller and memory modules to achieve higher DDR5 speed.
Low Signal Loss PCB
Server grade mid-loss or low-loss PCB material is chosen to lower signal loss inside PCB and maintain DDR5 high speed signal transmission.
Optimal VRM Design
Optimal Power
Maximum Turbo Boost and overclocking performance.
Hybrid VRM Design
To ensure maximum Turbo Boost and overclocking performance of Intel's new generation CPU, GAMING series motherboard equip the best VRM design ever built with the highest quality components.
8 VCORE Phases DrMOS 60A
To unleash full potential of multi-cores CPU performance.
1 VCCGT Phase DrMOS 50A
For CPU integrated GPU performance.
1 VCCAUX Phase
Provide stable power for CPU integrated PCIe & Memory controller.
All-Round Connectivity
Experience ultimate connectivity with next-generation network, storage, and Wi-Fi solutions, delivering lightning-fast data transfer speeds.
- Wi-Fi 6E
- 2.5GbE LAN
- Front USB-C® 10Gb/s
802.11ax Wi-Fi 6E
The latest Wireless solution 802.11ax Wi-Fi 6E with new dedicated 6GHz band, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4X range over BT 4.2 and with faster transmission.
- Up to 5.5x Faster Transmission Speed (Mbps) - 2400 (2x2 802.11ax)
*Based on WIFI theoretical bandwidth
Benefit of Wi-Fi 6E
- Dedicated spectrum in 6GHz band for less interference
- 4X better network capacity, no traffic jams especially in those dense area with lots of devices
- Network efficiency increase for better user experience
Wi-Fi 6E Bring You the Ultimate VR Experience!
Wi-Fi 6E brings faster Wi-Fi speeds, lower latency, and better battery life for VR devices, which means streaming VR games wirelessly from your PC to your VR device offers a lot smoother and has higher quality video.
Wi-Fi 6E Compared to Wi-Fi 5 Provide
- 40% faster speed for smoother gaming/streaming experience
- 50% higher resolution for video game related content
- Better battery life for VR devices
Wi-Fi 6E Advantage
Spectrum congestion is huge problem in current Wi-Fi environment nowadays because too many devices all use existing 2.4GHz and 5GHz spectrum, and it cause unreliable connection and slower speed. Wi-Fi 6E is extended standard to Wi-Fi 6, and it use dedicated 6GHz band that it provides not only brand new frequency to transfer data, but also spacious spectrum for future more devices. With Wi-Fi 6E, users can enjoy faster connection and stronger signal than before.
2.5G LAN
Design deliver blisteringly fast transfer speeds to ensure the most stable transmission environment when the system is performing cloud computing or providing external computing services.
Connecting the Future - Front USB3.2 Gen 2 Type-C®
USB 3.2 Gen 2 provides USB 3.2 Gen 2 ports with speeds up to 10Gbps. With twice the bandwidth compared to its previous generation as well as backwards compatibility with USB 2.0 and USB 3.2 Gen1, the much improved USB 3.2 Gen 2 protocol is available over the new reversible USB Type-C™ and the traditional USB Type-A connector for better compatibility over a wider range of devices.
- USB 3.2 Gen 2 - Up to 10Gb/s (Up to 2x Faster)
*Theoretical Bandwidth
Hi-Fi Audio
- High-End Audio Capacitors
- Audio Noise Guard
High-End Audio Capacitors
These high quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects.
Audio Noise Guard
Essentially separates the board's sensitive analogue audio components from potential noise pollution at the PCB level.
Personalisation
Customise to Fit Your Unique Personality
GIGABYTE motherboards bundle several useful and intuitive software to help users to control every aspect of motherboard and provide customisable lighting effect with outstanding aesthetics to fit your unique personality.
UC BIOS
Redesigned UI and UX
An intuitive operation interface with an aesthetically pleasing design.
Quick Access
9 customisable option slots for effortless access in Easy Mode.
PerfDrive
Exclusive BIOS settings that optimise the performance based on the cooling configuration.
Enhanced Intuitive UX
GIGABYTE User-Centred(UC) BIOS has enhanced the BIOS UX to provide users with an optimised experience featuring an intuitive operation interface and an aesthetically pleasing design.
Quick Access Function
GIGABYTE UC BIOS' Quick Access function selects 9 practical preset options from ADVANCE MODE and places them in EASY MODE for effortless access without switching or searching.
GIGABYTE PerfDrive
PerfDrive technology integrates exclusive BIOS settings from GIGABYTE, enabling easy balance of performance, power consumption, and temperature with Intel® Core™ processors.
Max Turbo
Unleashes the maximum Turbo Boost speed of Intel® Core™ CPUs.
Optimisation Mode
Strikes a balance between high performance and low temperature for Intel® Core™ CPUs.
Spec Enhance Mode
Enables high-performance operation of Intel® Core™ CPUs at lower temperature settings.
E-Core™ Disable Mode
Dedicates CPU resources exclusively to the P-core, enhancing gaming performance while reducing overall power consumption.
GIGABYTE Control Center
Unified software platform for all Gigabyte supported products.
- Intuitive user interface
- Modularised control
- Auto update
One Unified Platform to Connect All Devices
GIGABYTE Control Center (GCC) is a unified software platform across a variety of GIGABYTE products. Every available utility preferred is optimised and integrated with intuition into this one-stop center.
Get What You Want
Pick up dedicated utilities for your supported hardware with GCC while the Update center maintains the product up to date.
See What You Need
Unified user interface for a variety of supported products, providing a intuitive approach for performance adjustments, fan control, and customisable RGB aesthetics.
As Easy as Possible
Intuitive user experience to accomplish tasks with ease and consistency across a variety of supported products.
Centralised Update Management
The Update Center will check for driver or utility updates on a regular basis through our cloud servers to provide a overall stable system.
Spotlight Your Flair
Liberate your imagination using GCC's versatile illumination options for your motherboard. Tailor your setup with eye-catching displays that mirror your unique personality and preferences.
Varnish Your Shine
Programmable RGB LED connectors enable precise control over individual LEDs (for ARGB GEN2 devices), seamlessly managed through the GCC.
* The information provided is for reference; please prioritise your specific setup and specifications.
- 1x RGB LED header
- 3x ARGB LED headers
