10yrsThe FSP VITA GM Gold Modular ATX 3.1 1000W Power Supply delivers efficient, reliable power for modern gaming and performance PC builds. Complies with the latest ATX 3.1 and PCIe 5.1 standards, it includes a 12V-2x6 cable connector for next-gen graphics cards. With 80 PLUS Gold and Cybenetics Gold certifications, the VITA GM ensures high energy efficiency and stable power output. Its fully modular design allows for clean and flexible cable management, while the 120mm hydraulic bearing fan provides quiet, effective cooling. Built with high-quality components including 105°C Japanese capacitors, and features comprehensive protection such as OVP, OCP, OPP, OTP, SCP, UVP, SIP and NLO, for maximised reliability, performance and power efficiency.
Features
VITA GM 1000W White
- Complies with ATX 12V V3.1 & EPS 12V V2.92
- Efficiency ≧ 90% at typical load
- 80 PLUS ® gold certified
- 105°C Japanese bulk capacitor
- 120mm hydraulic bearing ( HYB ) fan
- Fully modular cabling design
- Complete protections: OVP, OCP, OPP, OTP, SCP, UVP, SIP, NLO
Complies with Intel ® Power Design Guide ATX 3.1
Built for the demanding power requirements of tomorrow, these PSUs offer maximum total power excursion support as per ATX 3.1 and PCIe Gen 5.1 specifications, ensuring peak performance with future hardware upgrades.
High Efficiency in Gold-Certified
Certified by world-class organisations 80 PLUS® gold certifications and reach platinum efficiency at typical load for lower power loss, less heat, and quieter operation.
LLC Resonant-Converter Topology with Synchronous Rectifier
Reducing switching losses, boosting efficiency, and keeping the output voltage regulated under load conditions.
+5V & 3.3V DC to DC Circuit Design
Increase the efficiency and stabilise the output voltage to ensure system stability.
105°C Japanese Bulk Capacitor
Equip your PC with the best-in-class capacitors to offer maximise reliability, performance, and lasting power.
120 mm Hydraulic Bearing (HYB) Fan
Quality bearing keeps fan noise to a minimum while providing maximum cooling performance.
Powerhouse Single +12V Rail
This high-amperage +12V rail delivers high load capabilities, it’s ideal for intensive workloads of high-performance CPUs and graphics cards.
The Force Comes with You
Individual CPU 4+4 pin cables provide CPU direct output power to ensure stable operation even under the most demanding workloads.
Dual PCIe 6+2Pin cables and a versatile 12V-2x6 cable offer flexible configuration for even the most power-hungry NVIDIA or AMD graphics cards.
Modular Design with All-White Cables
The VITA GM white version features completely white modular cables and cable connectors, creating an ultra-cool, all-white aesthetic. Its fully modular cabling design makes power supply installation easy, allowing users to use only the needed cables, which improves airflow and reduces system clutter.
Compact PSU Size：140 x 150 x 86mm
140mm in length which is relatively shorter than industry standard, it’s ideal for compact PC or space-constraint environment without compromising on performance.
Fortress-Level Protection
Our comprehensive circuit shields your valuable components from harm.
- OVP - Over Voltage Protection
- OCP - Over Current Protection
- OPP - Over Power Protection
- OTP - Over Temperature Protection
- SCP - Short Circuit Protection
- UVP - Under Voltage Protection
- SIP - Surge and Inrush Protection
- NLO - No-load Operation
Backed by a 10 year FSP warranty.
