Epic Price! The TP-Link Archer TX10UB Nano is an AX900 Wi-Fi 6 and Bluetooth 5.3 Adapter, supporting Wi-Fi speeds of up to 900 Mbps, and a reliable Bluetooth 5.3 connection. Coming in a compact design, having an easy setup process, advanced security protocols, and supporting compatibility for Windows 10 and 11.
Features
AX900 Nano Wi-Fi 6 Bluetooth 5.3 USB Adapter
Wi-Fi and Bluetooth Two in One
- High Speed Wi-Fi – Up to 900 Mbps speeds with 287 Mbps on 2.4 GHz and 600 Mbps on 5 GHz, upgrades your devices to higher AX Wi-Fi speeds.
- Dual Band Wireless – 2.4GHz and 5GHz band for flexible connectivity, upgrades your devices to work with the latest dual-band Wi-Fi router for faster speed and extended range.
- Reliable Bluetooth 5.3 – Bluetooth 5.3 has been enhanced in terms of reliability and security, which ensures a more robust coordination with your game controllers, headphones, keyboards an etc.
- Nano design – Small, unobtrusive design allows you to plug it in and forget it is even there
- Operating System – Supports Windows 11/10
- Advanced Security – Supports WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK, WPA3-SAE encryption standards
Wi-Fi 6 Upgrades Everything
Super-fast Wi-Fi 6 makes annoying lag and endless loading a thing of the past. Equip your PC with TX10UB Nano and enjoy the future of faster network loads and more connections.
Lower Latency, Higher Efficiency, and Less Congestion
MU-MIMO
Experience flawless streams, gameplay, and uploads while your network simultaneously processes bandwidth for multiple devices.
OFDMA
Working with a compatible router, your PC receives data at the same time as other devices on the same stream. This means next-to-nothing lag for video and games.
More Robust Bluetooth 5.3
Inheriting the high speed and broad coverage of last-gen Bluetooth, Bluetooth 5.3 has also been enhanced in terms of reliability and security, which ensures a more robust coordination with your game controllers, headphones, keyboards an etc.
Advanced Security with WPA3
The latest Wi-Fi security protocol, WPA3, brings new capabilities to improve cybersecurity in personal networks. More secure encryption in Wi-Fi password safety and enhanced protection against brute-force attacks combine to safeguard your home Wi-Fi.
Miniature Design Brings Infinite Convenience
Archer TX10UB Nano is designed to be as convenient as possible. With its miniature size and sleek design, you can connect the nano adapter to any USB port and leave it there, whether you are traveling or at home.
Setup Made Easy
TX10UB Nano comes with its driver pre-loaded. Just plug and install.
Operating Systems
Works with Windows 11/10.
Specifications
General Data
| Model Number |
ARCHER-TX10UB-NANO |
| Certification |
CE, FCC, RoHS |
| Package Contents |
AX900 Nano Wi-Fi 6 Bluetooth 5.3 USB Adapter Archer TX10UB Nano
Quick Installation Guide |
| System Requirements |
Windows 11 / 10 |
| Environment |
Operating Temperature: 0 ~ 40 (32 ~ 104)
Operating Humidity: 10% ~ 90% non-condensing |
Hardware Features
| Interface |
USB 2.0 |
| Dimensions (W x D x H) |
19.2 x 15.7 x 7.4 mm |
| Antenna |
Omni Directional |
Wireless Features
| Wireless Standards |
IEEE 802.11b / g / n / ax 2.4 GHz, IEEE 802.11a / n / ac / ax 5 GHz |
| Frequency |
5 GHz
2.4 GHz |
| Signal Rate |
5 GHz
11ax: Up to 600 Mbps (dynamic)
11ac: Up to 433 Mbps (dynamic)
11n: Up to 150 Mbps (dynamic)
11a: Up to 54 Mbps (dynamic)
2.4 GHz
11ax: Up to 287 Mbps (dynamic)
11n: Up to 200 Mbps (dynamic)
11g: Up to 54 Mbps (dynamic)
11b: Up to 11 Mbps (dynamic) |
| Reception Sensitivity |
5 GHZ:
11a6M: -94 dBm
11ax HE80 MCS11: -59 dBm
11ax HE80 MCS0: -87 dBm
2 GHZ:
11g6M: -95 dBm
11ax HE40 MCS11: -65 dBm
11ax HE40 MCS0: -93 dBm |
| Wireless Modes |
Infrastructure Mode |
| Wireless Security |
WEP, WPA / WPA2 / WPA3, WPA-PSK / WPA2-PSK |
| Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM,
256-QAM, 1024-QAM |
Backed by a 3 year TP-Link warranty.
