AMD Ryzen 5 5600XT with Wraith Stealth
100-100001585BOX | AMDThis product has been discontinued
The AMD Ryzen 5 5600XT is a 6 Core 12 Thread CPU featuring a 3.7GHz Base Clock, 4.7GHz Boost clock, 65W TDP, 32MB L3 cache and includes AMD Wraith Stealth cooler.
Specifications
General Data
| Model Number | 100-100001585BOX |
| Family | Ryzen |
| Series | Ryzen 5000 Series |
| Form Factor | Desktops, Boxed Processor |
| Market Segment | Mainstream Desktop |
| Consumer Use | Yes |
| Regional Availability | Global, China, NA, EMEA, APJ, LATAM |
| Former Codename | Vermeer |
| Architecture | Zen 3 |
| No of CPU Cores | 6 |
| Multithreading (SMT) | Yes |
| No of Threads | 12 |
| Max. Boost Clock | Up to 4.7 GHz (Max boost for AMD processors is the maximum frequency achievable by a single core on the processor running a bursty single-threaded workload. Max boost will vary based on several factors, including, but not limited to: thermal paste; system cooling; motherboard design and BIOS; the latest AMD chipset driver; and the latest OS updates. GD-150.) |
| Base Clock | 3.7 GHz (Represents the average effective base frequency of all cores.) |
| L1 Cache | 384 KB |
| L2 Cache | 3 MB |
| L3 Cache | 32 MB |
| Default TDP | 65W |
| Processor Technology for CPU Cores | TSMC 7nm FinFET |
| Processor Technology for I/O Die | 12nm (GlobalFoundries) |
| CPU Compute Die (CCD) Size | 74mm² |
| I/O Die (IOD) Size | 125mm² |
| Package Die Count | 2 |
| Unlocked for Overclocking | Yes (AMD's product warranty does not cover damages caused by overclocking, even when overclocking is enabled via AMD hardware and/or software. GD-26.) |
| CPU Socket | AM4 |
| Supporting Chipsets | X570, X470, X370, B550, B450, B350, A520 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) | AMD Wraith Stealth |
| Max. Operating Temperature (Tjmax) | 95°C |
| OS Support | Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
| Graphics Model | Discrete Graphics Card Required |
|
Supported Technologies |
AMD Store MI Technology, AMD Ryzen™ Master Utility, AMD Ryzen™ VR-Ready Premium |
Connectivity
| Native USB 3.2 Gen 2 (10Gbps) | 4 |
| Native SATA Ports | 2 |
| PCI Express® Version | PCIe® 4.0 |
| Native PCIe® Lanes (Total/Usable) | 24, 20 |
| Additional Usable PCIe Lanes from Motherboard | X570 16 x Gen 4 X470 2 x Gen 3, 8 x Gen 2 |
| NVMe Support | Boot, RAID0, RAID1, RAID10 |
| System Memory Type | DDR4 |
| Memory Channels | 2 |
| Max. Memory | 128 GB |
| System Memory Subtype | UDIMM |
| System Memory Specification | Up to 3200 MT/s |
| Max Memory Speed | 2 x 1R DDR4-3200 2 x 2R DDR4-3200 4 x 1R DDR4-2933 4 x 2R DDR4-2667 |
| ECC Support | Yes (Requires mobo support) |
Backed by a 3 year AMD warranty.
