The PowerColor Radeon RX 9070 Red Devil OC 16GB gaming graphics card features a 2170MHz silent gaming clock, 2700MHz OC boost clock, 256-bit memory interface, 16GB GDDR6 VRAM, 20Gbps memory speed, PCIe 5.0, 1 x HDMI 2.1, 3 x DisplayPort 2.1a, OpenGL 4.6 and DirectX 12 support.
Features
Red Devil AMD Radeon™ RX 9070 16GB GDDR6 - Unleash the Gaming Power
Dual BIOS
Choosing the BIOS that fits your need: better overclocking or silent operation.
Intelligent Fan Controller
Utilising temperature detection from a smart chip, fans will start running when the GPU reaches 60°c and shut down below 50°c.
Triple Ring-Fan
The 3X100mm Ring-fan design improves the cooling performance.
PowerColor Keystone
Keystone unifies your PowerColor devices in one hub. Customise lighting patterns, tweak DPI and macros, or adjust DTS and EQ settings. It's all about simple, powerful control for serious gamers.
GPU Direct-Contact Copper Plate
A large copper plate provides direct contact with the GPU while covering VRAM area to increase the heat transfer threshold to the max.
Hellstone
Hellstone RGB lighting adds a powerful, gem-inspired radiance to your graphics card. Designed for PowerColor’s Red Devil series, it creates a fierce, customisable light show that stands out in any build.
Specifications
| Model Number |
RX9070-16G-E/OC |
| Graphics Engine |
RX9070 16G-E/OC |
| Video Memory |
16GB GDDR6 |
| Stream Processor |
3584 Units |
| Engine Clock |
Game: 2210 MHz(OC)/ 2170 MHz(Silent)
Boost: 2700 MHz(OC)/ 2650 MHz(Silent) |
| Memory Speed |
20.0 Gbps |
| Memory Interface |
256-bit |
| Bus Standard |
PCIE 5.0 x 16 |
| Display Connectors |
1 x HDMI 2.1 , 3 x DisplayPort 2.1a |
| Form Factor |
ATX |
| Cooler |
3 Slot Triple Fan |
| Power Connector |
Two 8-pin PCI Express Power Connector |
| OpenGL |
4.6 |
| DirectX® Support |
12 |
| Minimum System Power |
800 W |
| Card Dimension (mm) |
340 x 132 x 69mm
352 x 149 x 69mm(w/bracket) |
| Accessories Bundle |
Graphics Card Holder
Addressable RGB LED Cable
Red Devil Nameplate
Devil Gallery Card
Gaming Gear Intro Card |
| Notes |
* 'Game Clock' is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
* 'Boost Clock' is the maximum frequency achievable on the GPU running a burst workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. |
Backed by a 3 year PowerColor warranty.
