The Cooler Master V SFX power supply is 80PLUS Gold certified and delivers excellent performance, 750W capacity with 100% Japanese capacitors, ATX 3.1 support and a durable 90-degree 12V-2x6 cable, a 92mm fluid dynamic bearing fan, and is fully modular.
Features
V SFX Gold 750 ATX 3.1
- Flexible compatibility
- ATX 3.1 support & a 90-degree 12V-2x6 cable
- 80 PLUS Gold certified
- Fully modular cabling
- 100% Japanese capacitors
- 10-year Warranty
Small But Mighty
As the leading SFX power supply design, the V SFX Gold offers a highly powerful unit in a space-saving, mini form factor.
Flexible Compatibility
With the included SFX-to-ATX bracket, the V SFX Gold ATX 3.1 can be used to power systems ranging from as small as a mini-ITX all the way up to E-ATX motherboards.
ATX 3.1 Support & A Durable 90-Degree 12V-2 x 6 Cable
Includes ATX 3.1 support and a 90-degree 12+4pin (12V-2x6) PCIe 5.1 connector featuring higher electrical durability, lower temperatures, and improved safety.
80 Plus Gold Certified
The V SFX Gold is certified to achieve more than 90% efficiency at typical loads.
100% Japanese Capacitors
Large, high-quality Japanese capacitors feature improved efficiency and reduced ripple noise.
Fully Modular Cabling
Modular cabling reduces clutter, increases airflow, and improves overall thermal performance.
Specifications
| Model Number |
MPY-7501-SFHAGV-3EAU |
| ATX Version |
ATX 3.1 & SFX 12V Ver. 3.42 |
| PFC |
Active PFC |
| Input Voltage |
100-240V |
| Input Current |
10-5A |
| Input Frequency |
50-60Hz |
| Dimensions (L x W x H) |
100 x 125 x 63.5 mm |
| Fan Size |
92mm |
| Fan Bearing |
FDB |
| Efficiency |
90% @ Typical Load |
| 80 PLUS Rating |
80 PLUS Gold |
| ErP 2014 Lot 3 |
Yes |
| Operating Temperature |
0-50°C |
| Power Good Signal |
100 - 500 ms |
| Hold Up Time |
16ms |
| MTBF |
>100,000 Hours |
| Protections |
OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection |
| Regulatory |
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA |
| ATX 24 Pin Connectors |
1 |
| EPS 4+4 Pin Connectors |
1 |
| EPS 8 Pin Connector |
1 |
| SATA Connectors |
8 |
| Peripheral 4 Pin Connectors |
4 |
| PCI-e 6+2 Pin Connectors |
4 |
| 12V-2x6 Connectors |
1 |
| Series |
V SFX Series |
| 80 Plus Efficiency |
Gold |
| Modular |
Fully Modular |
| Form Factor |
SFX |
| Watts |
750W |
Backed by a 10 year Cooler Master warranty.
