The H9 Elite is designed to show off every angle of your build with a tempered glass top panel and a built-in RGB & Fan Controller. The unique wraparound glass design with a dual-chamber layout is the perfect showcase for premium components.
Features
H9 Elite
Premium Dual-Chamber Mid-Tower Airflow Case
The H9 Elite is designed to show off every angle of your build with a tempered glass top panel and a built-in RGB & Fan Controller. The unique wraparound glass design with a dual-chamber layout is the perfect showcase for premium components.
- Unique uninterrupted glass panel for a clear view of the interior
- Intuitive cable management and dual chamber design
- Room for ten fans or three 360mm Radiators
- Tempered glass top panel and included RGB & Fan Controller
- Direct airflow to the GPU for handling high-powered components
- Enhanced experience with other products from the NZXT ecosystem
- Includes three F Series 120mm RGB Duo Fans and one F120Q Fan (Case Version)
GPU Capacity
The H9 Elite has 435mm of GPU clearance, offering room for the latest NVIDIA 40 Series and AMD 7000 Series cards.
Fan Capacity
The H9 Elite has room for 10 fans. With the capacity for 3x120mm fans on the side, 3 x 120mm or 2x140mm on the top and bottom, and 1 x120mm on the rear.
Radiator Capacity
The H9 Elite has room for up to a 360mm radiator on the top, bottom, or side, and up to a 120mm radiator on the rear.
Inside the Box
- H9 Elite Case x 1
- 120mm RGB Duo Fan x 3
- 120mm Quiet Airflow Fan (Case Version) x 1
- RGB and Fan Controller x 1
- Installation Accessories x 1
- Manual x 1
Specifications
| With Feet |
W: 290mm H: 495mm D: 466mm |
| Without Feet |
W: 290mm H: 465mm D: 466mm |
| Material(s) |
SGCC Steel, Tempered Glass |
| Weight |
13.9 kg |
| Motherboard Support |
ATX, Micro-ATX, mini-ITX |
| I/O Ports |
2 x USB 3.2 Gen 1 Type-A
1 x USB 3.2 Gen 2 Type-C
1 x Headset Audio Jack |
| Filters |
All Air Intakes |
| Included Accessories |
Installation screws
10 x Cable ties |
| RGB & Fan Controller |
Fan Channels: 3
NZXT RGB Connector: 6 (Support up to 120 LEDs) |
| Expansion Slots |
7 |
| Drive Bays |
| 2.5” |
4 + 2 |
| 3.3.5” |
2 |
| Radiator Support |
| Side |
UP to 360mm (120/240/360mm) |
| Top |
UP to 360mm (120/140/240/280/360mm) |
| Bottom |
UP to 360mm (120/140/240/280/360mm) |
| Rear |
UP to 120mm |
| Fan Support |
| Side |
3 x 120mm |
| Top |
3 x 120mm / 2 x 140mm |
| Bottom |
3 x 120mm / 2 x 140mm |
| Rear |
1 x 120mm |
Backed by a 2 year NZXT warranty.
