The MOZA SRP2 Pedals feature customisable brake feel settings to deliver precise and responsive control for sim racing enthusiasts. Constructed from CNC-machined aerospace-grade aluminium and high strength steel, the SRP2 offers adjustable pedal positioning, tool-free tuning, and integration with MOZA Pit House software for a tailored racing experience.
Features
MOZA SRP2 Pedals
Precision-engineered MOZA SRP2 Dual Pedals feature CNC aerospace-grade aluminium and high-strength steel for durable, professional-grade performance. Equipped with a 100KG load cell and 15-bit angle sensor with fusion technology, the SRP2 delivers accurate, responsive brake input. Fully adjustable pedal angle, spacing, and height, combined with tool-free tuning and optional Performance Kit for 1,000+ brake feel configurations, ensure a customisable and immersive sim racing experience. Compatible with PC and Xbox.
*Pedal Set of 2- No Clutch
Brake Feel Adjustment with Elastomer and Spring
The standard setup features an elastomer structure with multiple spring hardness options (60R, 70R, and 80P), offering 25 distinct brake feel configurations. The optional Performance Kit provides additional elastomers and springs, enabling over 1,000 customisable brake feel settings.
Aerospace-Grade Aluminium Construction with CNC Precision Machining
Pedal components are made from aerospace-grade aluminium, precision-machined using CNC technology, and anodised for enhanced durability. The base and pedal linkages are constructed from high-strength steel to withstand high torque and pressure.
100Kg High-Precision Load Cell
Featuring a 100Kg load cell, this sensor provides highly accurate and responsive brake input, making it ideal for users seeking precise control.
15-Bit High-Precision Angle Sensor
Utilising patented sensor fusion technology, this system combines a 15-bit angle sensor with the load cell, ensuring precise brake inputs while leveraging muscle memory for accurate control over braking force.
Adjustable Pedal Angle
The pedals feature a full 25° of angle adjustment allowing for better customisation to suit different user preferences and ergonomic needs.
Adjustable Pedal Position and Height
The spacing between the brake, throttle, and clutch pedals can be easily adjusted, with the option to fine-tune the distance (±15mm left/right) by adjusting the pedal installation position. Additionally, the pedal height is individually adjustable with a range of 36mm.
Desktop-Optimised Design
The angle of the pedal arm is tailored for desktop racing setups, aligning with natural seating and foot positioning.
Optional Wall Support Bracket
An optional wall support bracket is available to further stabilise the pedals, preventing sliding and enhancing comfort during use.
Adjustable Throttle and Clutch Feel
Both the throttle and clutch pedals feature a spring-loaded, enclosed design with a smooth guiding rod, allowing for quick manual adjustment of preload in two levels, ensuring a smooth and responsive feel.
Extremely Smooth and Quiet Operation
The enclosed sleeve motion structure and highly polished steel shafts ensure exceptionally smooth and quiet pedal movements. Soft cushioning at the limit points further reduces noise, providing a more immersive experience.
Tool-Free Adjustment
The pedal system is designed for quick, tool-free force adjustments, allowing you to modify brake feel and force levels with just your hands.
Xbox & PC Compatibility
The pedals are compatible with both Xbox and PC. You can connect them directly to a PC via USB or use them with the Xbox-compatible ESX steering wheel to play Xbox racing games.
Professional Software Support
With the Pit House software, you can monitor pedal performance, adjust pedal travel and signal output curves, and view real-time data, allowing the hardware to perform at its full potential.
Optional Performance Kit
The optional performance kit includes 10 moulded springs, rubber springs, and metal blocks, which can be combined with the standard setup to provide over 1,000 possible brake feel configurations. This kit can replicate the stiff brake feedback found in high-performance racing cars like F1 and LMP1, allowing for ultra-fast brake response times.
Extreme Durability
Both the throttle and clutch pedals feature a spring-loaded, enclosed design with a smooth guiding rod, allowing for quick manual adjustment of preload in two levels, ensuring a smooth and responsive feel.
Backed by a 1 year MOZA warranty.
