Cooler Master MasterBox MB520 RGB TG Mid Tower
MCB-B520-KGNN-RGB | Cooler MasterThis product has been discontinued
Features
MasterBox MB520 RGB
Light 'em Up.
- Support for a Total of 6 Fans and Water Cooling
- Graphics Card Support Up to 410mm
- Storage Trays and Full-Length PSU Shroud
Darkmirror Front Panel
Shade light through a transparent, tinted front panel.
Performance Intake
Large intakes on each side of the front panel let the system breathe easy.
RGB LED Fans and Lighting Control
Three 120mm RGB LED fans in front are pre-installed to create an amazing lighting effect.
One RGB controller is included in the accessory pack. If your motherboard does not support the RGB control function, you can connect the RESET button and control the RGB lighting directly from the I/O panel.
Excellent Thermal Performance
Optimized airflow due to the large intakes on each side of the front panel. Additional ventilation on the top panel adds thermal support.
Fan and Radiator Support
Front: Three 120mm or two 140mm* fans and up to a 360mm radiator with a maximum thickness of 50mm without fans.
Top: Two 120mm or two 140mm fans and supports a 120mm or a 240mm radiator.
Rear: One 120mm fan or radiator. All to ensure you don’t have to compromise on performance.
* 2 x 140mm fans in front can only be mounted behind the front plate
Edge-to-Edge Tempered Glass Side Panel
Showcase your build and system lighting effect through the 4mm-thick tempered glass side panel. The side panel bracket hinges on an angle during removal, while two "captive" screws are held in place with rubber so they are not misplaced.
GFX Cable Routing
Conveniently route the graphics card cable through the PSU shroud grommet.
Expanding the Possibilities
The spacious interior fits all standard motherboards for your gaming needs.
- ATX
- Micro-ATX
- Mini-ITX
Main Components Clearance
The MB520 RGB case supports CPU Coolers up to a height of 165mm, Graphic Cards up to a length of 410mm, and Power Supplies up to a length of 180mm.
Specifications
| Model Number | MCB-B520-KGNN-RGB |
| Available Colour(s) | Black |
| Materials | Steel, Tempered Glass, Plastic |
| Dimensions (L X W X H) | 496 x 218 x 468mm |
| Motherboard Support | ATX, Micro ATX, Mini ITX |
| Expansion Slots | 7 |
| 2.5" / 3.5" Drive Bays (Combo) | 2 |
| 2.5" Drive Bays | 4 (Max. 6) |
| I/O Panel | 2x USB 3.0, Audio In & Out (Supports HD Audio) |
| RGB Control | RGB Controller Included, 1 to 3 RGB Splitter Cable Included |
| Pre-Installed Fans - Front | 3 x 120mm RGB Fan |
| Pre-Installed Fans - Rear | 1 x 120mm (Black) |
| Fans Support - Front | 3 x 120mm, 2 x 140mm |
| Fans Support - Top | 2 x 120mm,2 x 140mm |
| Fans Support - Rear | 1 x 120mm |
| Radiator Support - Front | 120mm, 140mm, 240mm, 280mm, 360mm |
| Radiator Support - Top | 120mm, 240mm |
| Radiator Support - Rear | 120mm |
| Clearance - CPU Cooler | 165mm / 6.49" |
| Clearance - GFX | 410mm / 16.1" |
| Clearance - PSU | 180mm / 7.1" |
| Cable Routing-Behind Motherboard Tray | 19-27mm / 0.74-1.06" |
| Dust Filters | Front, Bottom, Top |
| Power Supply Support | Bottom Mount, ATX |
| Series | MasterBox Series |
| Size | Mid Tower |
