The PNY GeForce RTX 5070 Ti OC GDDR7 16GB graphics card features a 2295MHz boost clock (default mode), 2572MHz boost clock (OC mode), 16GB GDDR7 256-bit memory interface, 28Gbps memory speed, PCIe 5.0, 1 x HDMI 2.1b, 3 x DisplayPort 2.1b.
Features
PNY GeForce RTX™ 5070 Ti Overclocked Triple Fan GPU
Get game-changing performance with the GeForce RTX™ 5070 Ti, powered by NVIDIA® Blackwell. Game at high frame rates with DLSS 4, supercharge your creativity with NVIDIA Studio, and enable new experiences with the power of AI.
- NVIDIA Blackwell Architecture
- 16GB GDDR7 Memory
- 3x DisplayPort 1x HDMI
- 8,960 CUDA® Cores
- 300 W Thermal Design Power
NVIDIA Blackwell Architecture
The Ultimate Platform for Gamers and Creators
- Fifth-Gen Tensor Cores - Max AI performance with FP4 and DLSS 4
- New Streaming Multiprocessors - Optimised for neural shaders
- Fourth-Gen Ray Tracing Cores - Built for Mega Geometry
- AI-Enhanced Graphics and Performance - NVIDIA DLSS 4 with Multi Frame Generation
- Game-Winning Responsiveness - NVIDIA Reflex 2 with Frame Warp
- True-to-Life Graphics - Full ray tracing with neural rendering
- Digital Humans and AI Assistants - NVIDIA ACE
- Accelerate Your Creativity - NVIDIA Studio creator tools and technology
- Enhance Any Video with AI - NVIDIA Broadcast and ninth-gen NVIDIA Encoder
- Performance and Reliability - NVIDIA app with Game Ready and Studio Drivers and Studio Drivers
- The Ultimate Gaming Display Technologies - NVIDIA G-SYNC
Game Changer
Powered by NVIDIA Blackwell, GeForce RTX™ 50 Series GPUs bring game-changing capabilities to gamers and creators. Equipped with a massive level of Al horsepower, the RTX 50 Series enables new experiences and next-level graphics fidelity. Multiply performance with NVIDIA DLSS 4, generate images at unprecedented speed, and unleash your creativity with NVIDIA Studio.
Specifications
| Model Number |
VCG5070T16TFXPB1-O |
| Architecture |
Blackwell |
| CUDA® Cores |
8,960 |
| Clock Speed |
2.3 GHz |
| Memory Speed (Gbps) |
28 |
| Memory Size |
16 GB GDDR7 |
| Memory Interface |
256-bit |
| Memory Bandwidth (GB/sec) |
Up to 896 |
| TDP |
300 W |
| NVLink |
Not Supported |
| Outputs |
DisplayPort 2.1b (x 3), HDMI 2.1b |
| Multi-Screen |
4 |
| Resolution |
4K at 480 Hz or 8K at 120 Hz with DSC |
| Power Input |
16-pin (One 16-pin to Four 8-pin) |
| Bus Type |
PCI-Express 5.0 x 16 |
| Card Dimensions |
11.80" x 4.73" x 2.35"; 2.98 Slot |
| System Requirements |
PCI Express-compliant motherboard with one 2.98-width x 16 graphics slot
Two 8-pin supplementary power connectors
Total graphics power 300 W
Required system power 750 W (Power requirements can be different depending on system configuration.)
Microsoft Windows® 11 64-bit, Windows 10 (November 2018 or later) 64-bit, Linux 64-bit
Internet connection (Graphics Card driver is not included in the box; NVIDIA App will download the latest GeForce driver from the Internet after install.) |
| Package Contains |
PNY GeForce RTX™ 5070 Ti OC
1 x Auxiliary Power Cable |
| Warranty |
3-Year Limited Warranty |
Backed by a 3 year PNY warranty.
