The Antec Fusion 120 ARGB fan delivers a perfect balance of cooling performance and stunning aesthetics. Featuring a unique dodecagon-shaped lighting ring with vibrant ARGB illumination, it enhances any build with dynamic effects. With PWM control, speeds range from 600 to 2000 RPM, ensuring efficient airflow while maintaining low noise. The hydraulic bearing design offers smooth operation and extended lifespan, while anti-vibration pads reduce noise and enhance stability. Compatible with motherboard ARGB sync, the Fusion 120 is an excellent choice for those looking to add both cooling and style to their system.
Features
Fusion 120mm ARGB Fan
Create Your Charisma
The brand-new Fusion 120 ARGB case fan features a unique dodecagon-shaped lighting ring with 16 LEDs & a hydraulic bearing fan. It will bring you an unforgettable experience visually and functionally.
- RGB Sync (1.6 Million Colour)
- ASUS Aura Sync
- Gigabyte RGB Fusion Ready
- RGB MSI Mystic Light Sync
- ASRock Polychrome Sync
Lighting Frame Projects Various Lighting Effects
The unique dodecagon-shaped lighting ring with 16 LEDs projects various lighting effects from many angles.
- Advance Dual-Layer Design with Crystal Layer and Frosty Layers
Wonderful Texture
The well-processed fan structure and unique shape of fine craftsmanship bring the fan quality to the next level.
Compatible with the Motherboard
2 Individual Cable
Durable Woven Wire
The cable is covered with durable woven wire to enhance the lifetime & create unique aesthetics.
4-Pin PWM Connector
Connect to the motherboard. (50cm)
3-Pin ARGB Connector
Connect to the motherboard for ARGB sync. (50cm)
8 Enlarged Anti-Vibration Pads
The anti-noise design with 8 anti-vibration pads can efficiently reduce noise.
Hydraulic Bearing fan
Extends the lifespan and reduces the noise.
ARGB/PWM Controller
A. Fan: PWM Port (4 pin)
B. LED: ARGB port (3 pin)
C. DC-in: SATA Power Connector
D. LED Ctrl: External LED Connector (Or connect it to the reset hub and turn it into LED control.)
E. LED Speed: Control the speed of lighting effects. (Low/Mid/High)
F. PWM LED: External Signal Connector (Connect the motherboard for ARGB & PWM functions.)
G. Mode: Switch the lighting effects
Stunning ARGB lighting Effects & Massive Airflow
Specifications
| Model Number |
FUSION-120-ARGB |
| Model Name |
Fusion 120 ARGB |
| Fan Type |
PWM Fan |
| Dimensions |
120 x 120 x 25 mm |
| Bearing Type |
Hydraulic Bearing |
| LED Type |
Addressable RGB |
| Fan Speed |
600 ± 200 ~ 2000 ± 10% RPM |
| Airflow |
57.93 CFM (max.) |
| Air Pressure |
2.11 mmH₂O (max.) |
| Fan Noise Level |
17.02 ~ 31.24 dB(A) |
| Lifespan |
40,000 hours /hrs 25°c |
| Connector |
Fan: 4-pin PWM | LED: 3-pin |
| Rated Voltage |
Fan: DC 12 V | LED: DC 5 V |
| Operation Voltage |
Fan: DC 6.0 - 13.8 V | LED: DC 4.5 - 5.5 V |
| Rated Current |
Fan : ≤ 0.21 A | LED : ≤ 0.58 A |
| Package |
Fusion 120 ARGB Single Pack |
| Warranty |
2 years |
Backed by a 2 year Antec warranty.
