The InWin F5 Full Tower Case offers a customisable look with detachable front panels, allowing users to choose between elegant maple wood or modern tinted glass finishes. Designed for versatility, it supports back-connector motherboards and accommodates graphics cards up to 435mm in length. The case provides extensive cooling options with three pre-installed Neptune AN140 fans and supporting up to nine 140mm fans (front, top, rear and bottom) and radiator support up to 420mm (front, top and bottom). Innovative features such as a magnetic GPU holder and modular PCIe slots enable both horizontal and vertical GPU orientations, ensuring stability and display flexibility. Tool-less side panels and ample space for components enhance the building experience, making the F5 a premium choice.
Features
F5 Full Tower
Shift and Shuffle Your Front Panel
The F5’s front panel features detachable panels, providing the freedom to swap for various PC appearances. Make it your personal PC now!
Select Your Vibe
Elegant Maple Wood and Modern Tinted Glass offer different materials on a PC that blends into your home or office setting.
Versatile GPU Support
InWin has innovated a magnetic GPU holder and a modular PCI-E slot for dual GPU orientation to ensure GPU stability and displays the card horizontally or vertically.
* The PCI-E riser cable is not included in package.
Highly Expandable
The F5 supports Back-Connector motherboards, compatible with GPUs up to 435 mm, and possesses multiple 2.5”/3.5” storage drive trays.
* Supports ASUS BTF, MSI Project Zero Series and GIGABYTE Project STEALTH Back-Connector ATX motherboards.
Versatile Cooling Options
The F5 provides versatile cooling configurations, supporting up to 9 fans and accommodating radiator sizes of 240, 280, 360, and 420 mm. F5 comes with three complementary Neptune AN140/AN140P fans.
* AN140 x 3 for Black version
Attention to Details
a. Ample Space for PSUs
b. Dust Filter
c. Hassle-Free Design (Easily access the side panel with just your index finger.)
Specifications
| Model Number |
IW-CS-F5BLK |
| Colour |
Black |
| Case Type |
Full Tower |
| Materials |
SECC, Tempered Glass |
| M/B Compatibility |
12" x 13" E-ATX, ATX, Micro-ATX, Mini-ITX |
| Expansion Slots |
8 x PCI-E
3 x Vertical PCI-E
(Riser Cable Optional; Not Included in Package) |
| Maximum Compatibility |
GPU Length: 410 - 435 mm
CPU Heatsink Height: 180 mm |
| I/O Ports |
1 x USB 3.2 Gen 2x2 Type-C
2 x USB 3.2 Gen 1
HD Audio Combo (CTIA – SPK/Mic) |
| Internal Drive Bays |
2 x 3.5" / 4 x 2.5"
2 x 2.5" |
| Thermal Solution Compatibility |
Air Cooling Fans:
Front: 2 x 120 / 140 mm
Top: 3 x 120 / 140 mm
Rear: 1 x 120 / 140 mm
Bottom: 3 x 120 / 140 mm
(3 InWin AN140 / AN140P Fans Included)
Water Cooling Radiator:
Front: 1 x 240 / 280 mm
Top: 1 x 360 / 420 mm
Bottom: 1 x 360 / 420 mm |
| Power Supply Compatibility |
PSII: ATX12V
Length up to 230 mm |
| Product Dimensions (L x W x H) |
510 x 235 x 543 mm
20 x 9.2 x 21.3" |
| Net Weight |
10.73 kg /23.6 lbs |
Backed by a 2 year InWin warranty.
