The InWin F3 MicroATX Case is a compact yet versatile mini tower designed to accommodate micro-ATX and mini-ITX motherboards. It supports high-end graphics cards up to 340mm in length, making it suitable for both gaming setups and compact workstations. The case offers exceptional ventilation with one pre-installed AN120 fan and supporting up to six 120mm fans and radiator support of up to 280mm to the top, ensuring optimal airflow. Its back-connector motherboard design facilitates tidy cable management and allows for the installation of two HDDs or three SSDs.
Features
F3 Mini Tower
Redefine Your PC Aesthetic
Inheriting the classy F-Series design, the new F3 case offers a choice between elegant maple wood and modern glass, allowing your PC to fit your lifestyle and taste.
All About the Hardware Flair
The F3 accommodates micro-ATX motherboards and supports GPU lengths up to 340 mm. It can even fit high-end graphics cards to make it ideal for creating compact workstations capable of light AI computation or a killer gaming PC. The choice is yours!
Build Small. Play Big.
This case is compatible with SFF-Ready Enthusiast GeForce cards, so you can pack high performance into a smaller footprint. Look for SFF-Ready Enthusiast GeForce Cards to get a sure fit and streamline your PC build.
Back-Connector M/B Design
The F3 supports back-connecting motherboards provide tidier cable management and allows for easy installation of two HDDs or three SSDs.
* Supports ASUS BTF and MSI Project Zero Series back-connector mATX motherboards.
Breathe Easy
The F3 boasts exceptional ventilation by supporting up to six fans. Two 120/140 mm fans or a 240/280 mm AIO coolers can be installed on the top. The front mesh panel allows for ample ventilation.
* AN120 x 1 for Black version
Hassle-Free Design
Simplify your building experience with our hassle-free design.
Dust Filter
Efficiently reduces the entry of dust particles, providing a flexible and effective solution for cleaning your system.
The Clean Scene
With a back-connector motherboard design, cable management in a micro-ATX case can be neat and tidy.
Specifications
| Model Number |
IW-CS-F3BLK-1AN120 |
| Colour |
Black |
| Case Type |
Mini Tower |
| Materials |
SECC, Tempered Glass |
| M/B Compatibility |
Micro-ATX, Mini-ITX |
| Expansion Slots |
4 x PCI-E |
| Maximum Compatibility |
GPU Length: 340 mm
CPU Heatsink Height: 160 mm |
| I/O Ports |
1 x USB 3.2 Gen 2x2 Type-C
2 x USB 3.2 Gen 1
HD Audio Combo (CTIA – SPK/Mic) |
| Internal Drive Bays |
1 x 3.5" / 2.5"
1 x 3.5" / 2 x 2.5" |
| Thermal Solution Compatibility |
Air Cooling Fans:
Front: 1 x 120 mm
Top: 2 x 120 / 140 mm
Rear: 1 x 120 mm
Bottom: 2 x 120 mm
(1 InWin AN120 / AN120P Fan Included)
Water Cooling Radiator:
Top: 1 x 240 / 280 mm |
| Power Supply Compatibility |
PSII: ATX12V
Length up to 160 mm (cable management Included) |
| Product Dimensions (L x W x H) |
460 x 215 x 359 mm
18.1 x 8.5 x 14.1" |
| Net Weight |
7.25 kg / 16 lbs |
Backed by a 2 year InWin warranty.
